857-072 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 72POS 0.156
| Part | Termination Rows [custom] | Material - Insulation | Number of Positions/Bay/Row | Contact Material | Card Type | Read Out | Number of Positions | Number of Rows [custom] | Gender | Operating Temperature [Max] | Operating Temperature [Min] | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Termination | Mounting Type | Contact Finish | Contact Type | Card Thickness [Max] | Card Thickness [Min] | Color | Contact Finish Thickness | Contact Finish Thickness | Pitch | Pitch | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 36 | Copper Alloy | Non Specified - Dual Edge | Dual | 72 | 2 | Female | 125 °C | -40 C | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | Solder Eyelet(s) | Through Hole | Gold | Semi Bellows | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | |
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 36 | Copper Alloy | Non Specified - Dual Edge | Dual | 72 | 2 | Female | 125 °C | -40 C | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | Solder | Board Edge Straddle Mount | Tin | Semi Bellows | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 3.96 mm | 0.156 in | Card Extender | ||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 36 | Copper Alloy | Non Specified - Dual Edge | Dual | 72 | 2 | Female | 125 °C | -40 C | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | Solder | Board Edge Straddle Mount | Gold | Semi Bellows | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | Card Extender |
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 36 | Copper Alloy | Non Specified - Dual Edge | Single | 72 | 2 | Female | 125 °C | -40 C | Floating Bobbin Flush Mount | 0.116 " | 2.95 mm | Solder | Right Angle Through Hole | Tin | Semi Bellows | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 3.96 mm | 0.156 in | |||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 36 | Copper Alloy | Non Specified - Dual Edge | Single | 72 | 2 | Female | 125 °C | -40 C | Solder | Right Angle Through Hole | Tin | Semi Bellows | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 3.96 mm | 0.156 in | ||||||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 36 | Copper Alloy | Non Specified - Dual Edge | Dual | 72 | 2 | Female | 125 °C | -40 C | Flush Mount M3 Threaded Insert Top Opening | Solder | Through Hole | Tin | Semi Bellows | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 3.96 mm | 0.156 in | |||||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 36 | Copper Alloy | Non Specified - Dual Edge | Dual | 72 | 2 | Female | 125 °C | -40 C | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | Solder | Board Edge Straddle Mount | Tin | Semi Bellows | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 3.96 mm | 0.156 in | Card Extender | ||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 36 | Copper Alloy | Non Specified - Dual Edge | Dual | 72 | 2 | Female | 125 °C | -40 C | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | Solder | Board Edge Straddle Mount | Gold | Semi Bellows | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | Card Extender |
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 36 | Copper Alloy | Non Specified - Dual Edge | Single | 72 | 2 | Female | 125 °C | -40 C | Flush Mount M3 Threaded Insert Top Opening | Solder | Right Angle Through Hole | Tin | Semi Bellows | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 3.96 mm | 0.156 in | |||||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 36 | Copper Alloy | Non Specified - Dual Edge | Dual | 72 | 2 | Female | 125 °C | -40 C | Flush Mount M3 Threaded Insert Top Opening | Solder | Through Hole | Gold | Semi Bellows | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in |
