HXW Series

Manufacturer: Rubycon

Catalog

ALUMINUM ELECTROLYTIC CAPACITORS - RADIAL LEADED GENERAL PURPOSE ELECTROLYTIC CAPACITORS

Part	Polarization	Package / Case	Tolerance	Ripple Current @ Low Frequency	Size / Dimension [diameter]	Size / Dimension [diameter]	Applications	Lifetime @ Temp.	Capacitance	Lead Spacing	Lead Spacing	Voltage - Rated	Operating Temperature [Min]	Operating Temperature [Max]	Mounting Type	Ripple Current @ High Frequency	Height - Seated (Max)	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Height - Seated (Max) [Max] [custom]	Height - Seated (Max) [Max] [custom]	Height - Seated (Max) [Max] [z]
Rubycon 450HXW150MEFR18X35	Polar	Can Radial	20 %	980 mA	0.709 in	18 mm	General Purpose	3000 Hrs	150 µF	0.295 in	7.5 mm	450 V	-40 C	105 ░C	Through Hole	1.84 A	37 mm	1.457 in
Rubycon 400HXW100MEFR16X25	Polar	Can Radial	20 %	740 mA	0.63 in	16 mm	General Purpose	2000 Hrs	100 µF	0.295 in	7.5 mm	400 V	-40 C	105 ░C	Through Hole	1.11 A			1.063 in	27 mm
Rubycon 420HXW82MEFR18X20	Polar	Can Radial	20 %	620 mA	0.709 in	18 mm	General Purpose	2000 Hrs	0.082 mF	0.295 in	7.5 mm	420 V	-40 C	105 ░C	Through Hole	930 mA					0.866 in	22 mm
Rubycon 450HXW68MEFR10X55	Polar	Can Radial	20 %	640 mA	0.394 in	10 mm	General Purpose	2000 Hrs	68 µF	0.197 "	5 mm	450 V	-40 C	105 ░C	Through Hole	960 mA			2.244 "	57 mm
Rubycon 420HXW82MEFR12.5X35	Polar	Can Radial	20 %	640 mA	0.492 in	12.5 mm	General Purpose	2000 Hrs	0.082 mF	0.197 "	5 mm	420 V	-40 C	105 ░C	Through Hole	960 mA	37 mm	1.457 in
Rubycon 450HXW120MEFR18X30	Polar	Can Radial	20 %	840 mA	0.709 in	18 mm	General Purpose	3000 Hrs	120 µF	0.295 in	7.5 mm	450 V	-40 C	105 ░C	Through Hole	1.26 A		1.26 in					32 mm
Rubycon 420HXW120MEFR16X35	Polar	Can Radial	20 %	850 mA	0.63 in	16 mm	General Purpose	3000 Hrs	120 µF	0.295 in	7.5 mm	420 V	-40 C	105 ░C	Through Hole	1.275 A	37 mm	1.457 in
Rubycon 420HXW150MEFR18X30	Polar	Can Radial	20 %	920 mA	0.709 in	18 mm	General Purpose	3000 Hrs	150 µF	0.295 in	7.5 mm	420 V	-40 C	105 ░C	Through Hole	1.38 A		1.26 in					32 mm
Rubycon 450HXW68MEFR18X20	Polar	Can Radial	20 %	570 mA	0.709 in	18 mm	General Purpose	2000 Hrs	68 µF	0.295 in	7.5 mm	450 V	-40 C	105 ░C	Through Hole	1.188 A					0.866 in	22 mm
