142.5395.6302 Series

Fuse - BF2 58V / 1000A DC, 300A 200 pc

Manufacturer: Littelfuse/Commercial Vehicle Products

Catalog

Fuse - BF2 58V / 1000A DC, 300A 200 pc

Part	Package / Case	Fuse Type	Mounting Type	Voltage Rating - DC	Current Rating (Amps)	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [y]	Melting I²t	Breaking Capacity @ Rated Voltage	DC Cold Resistance	Response Time	Color
Littelfuse/Commercial Vehicle Products 142.5395.6302	Auto Link	Automotive	Bolt Mount	58 VDC	300 A	29 mm	18.8 mm	0.382 "	1.142 inches	9.7 mm	0.74 in	486000	1 kA	0.00021 Ohms	Slow Blow	Gray

Catalog

Fuse - BF2 58V / 1000A DC, 300A 200 pc

Key Features

• Grey housing indicates 300 A rating

• Tin-plated copper alloy terminals

• Refers to ISO 8820-5:2015

• UL Recognized in Canada and United States as a UL Special Purpose Fuse

Description

Use this 300 A BF2 58V bolt-down automotive fuse for short circuit protection along high-current wiring harnesses. It employs SLO-BLO® technology to deliver time-delayed performance.
