146 CTI Series

Catalog

ALUMINUM ELECTROLYTIC CAPACITORS - SMD 1000UF 50V 20%

Part	Size / Dimension Diameter	Ripple Current	Operating Temperature (Max)	Operating Temperature (Min)	Surface Mount Land Length	Surface Mount Land Width	Capacitance	Height - Seated (Max)	Mounting Type	Package / Case	Applications	Impedance	Voltage - Rated	Lifetime	Tolerance	Polarization	Ratings
Vishay Dale MAL214699111E3	0.63 in	1.5 A 900 mA	125 °C	-55 °C	0.63 in	0.63 in	1000 µF	0.866 in	Surface Mount	Can - SMD Radial	Automotive	52 mOhms	50 V	6000 Hrs	20 %	Polar	AEC-Q200
Vishay Dale MAL214699005E3	0.492 in	1.1 A 715 mA	125 °C	-55 °C	0.492 in	0.492 in	330 µF	0.551 in	Surface Mount	Can - SMD Radial	Automotive	75 mOhm	35 V	3000 Hrs	20 %	Polar	AEC-Q200
Vishay Dale MAL214699504E3	0.492 in	1.3 A 910 mA	125 °C	-55 °C	0.492 in	0.492 in	1000 µF	16.51 mm	Surface Mount	Can - SMD Radial	Automotive	58 mOhms	16 V	4000 Hrs	20 %	Polar	AEC-Q200
Vishay Dale MAL214699911E3	0.709 in	486 mA 810 mA	125 °C	-55 °C	0.709 in	0.709 in	330 µF	0.866 in	Surface Mount	Can - SMD Radial	Automotive	230 mOhms	100 VAC/DC	2500 Hrs	20 %	Polar	AEC-Q200
Vishay Dale MAL214699508E3	0.709 in	1.05 A 1.5 A	125 °C	-55 °C	0.709 in	0.709 in	3300 µF	0.689 in	Surface Mount	Can - SMD Radial	Automotive	50 mOhm	16 V	5000 Hrs	20 %	Polar	AEC-Q200
Vishay Dale MAL214699609E3	0.709 in	1.23 A 1.75 A	125 °C	-55 °C	0.709 in	0.709 in	2700 µF	0.866 in	Surface Mount	Can - SMD Radial	Automotive	35 mOhms	25 VAC	6000 Hrs	20 %	Polar	AEC-Q200
