CI3103P1 Series
Manufacturer: Cvilux USA
Beta
⌘K
3 POS 2.54MM(.100) WIRE TO BOARD
| Part | Contact Finish Thickness - Post | Contact Finish Thickness - Post | Insulation Color | Contact Type | Contact Finish - Post | Mounting Type | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Insulation Height | Insulation Height | Fastening Type | Number of Rows | Operating Temperature [Max] | Operating Temperature [Min] | Insulation Material | Connector Type | Number of Positions Loaded | Contact Shape | Overall Contact Length | Overall Contact Length | Contact Length - Mating | Contact Length - Mating | Material Flammability Rating | Contact Length - Post [x] | Contact Length - Post | Style | Contact Material | Pitch - Mating | Pitch - Mating | Shrouding | Termination | Voltage Rating | Current Rating (Amps) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Cvilux USA | 120 Áin | 3.05 Ám | Natural | Male Pin | Tin | Through Hole | 120 µin | 3.05 µm | 11.5 mm | 0.453 in | Friction Lock | 1 | 85 °C | -25 °C | Thermoplastic Halogen Free | Header | All | Square | 14.2 mm | 0.559 " | 7.49 mm | 0.295 in | UL94 V-0 | 0.134 " | 3.4 mm | Board to Cable/Wire | Brass | 0.1 " | 2.54 mm | Shrouded - 1 Wall | Solder | 250 VAC | 3 A |
