Schaffner FN9244 Series
Manufacturer: TE Connectivity AMP Connectors
Beta
⌘K
AC POWER ENTRY MODULES 12A SNAPIN/HORIZONT MEDICAL
| Part | Panel Thickness [Max] | Panel Thickness [Max] | Panel Thickness [Min] | Panel Thickness [Min] | Mounting Type | Filter Type | Features | Termination | Termination | Termination | Accomodates a Fuse | Approval Agency | Panel Cutout Dimensions [x] | Panel Cutout Dimensions [y] | Ingress Protection | Connector Type | Current Rating - Filter | Material Flammability Rating | Connector Style |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity AMP Connectors | 0.059 in | 1.5 mm | 0.028 in | 0.7 mm | Panel Mount Snap-In | Filtered (EMI RFI) - Commercial Medical | Bleed Resistor | 6.3 mm | Quick Connect | 0.25 " | CQC CSA ENEC UL | 28.5 mm | 21.9 mm | IP40 | Receptacle Male Blades | 12 A | UL94 V-2 | IEC 320-C14 | |
 TE Connectivity AMP Connectors | 0.059 in | 1.5 mm | 0.028 in | 0.7 mm | Panel Mount Snap-In | Filtered (EMI RFI) - Commercial | Earth Line Choke | 6.3 mm | Quick Connect | 0.25 " | CQC CSA ENEC UL | 29.4 mm | 20.8 mm | IP40 | Receptacle Male Blades | 15 A | UL94 V-2 | IEC 320-C14 | |
 TE Connectivity AMP Connectors | 0.087 " | 2.2 mm | 0.059 in | 1.5 mm | Panel Mount Snap-In | Filtered (EMI RFI) - Commercial | 6.3 mm | Quick Connect | 0.25 " | CE CQC CSA ENEC UL | 29.4 mm | 20.8 mm | IP40 | Receptacle Male Blades | 1.2 A | UL94 V-2 | IEC 320-C14 | ||
 TE Connectivity AMP Connectors | Flange Panel Mount | Filtered (EMI RFI) - Commercial | Earth Line Choke Front or Rear Side Mount | 6.3 mm | Quick Connect | 0.25 " | CQC CSA ENEC UL | IP40 | Receptacle Male Blades | 1 A | UL94 V-2 | IEC 320-C14 | |||||||
 TE Connectivity AMP Connectors | Flange Panel Mount | Filtered (EMI RFI) - Commercial Medical | Bleed Resistor Front or Rear Side Mount | 6.3 mm | Quick Connect | 0.25 " | CSA ENEC UL | IP40 | Receptacle Male Blades | 12 A | UL94 V-2 | IEC 320-C16 | |||||||
 TE Connectivity AMP Connectors | Flange Panel Mount | Filtered (EMI RFI) - Commercial | Bleed Resistor Earth Line Choke Front or Rear Side Mount | 6.3 mm | Quick Connect | 0.25 " | CQC CSA ENEC UL | IP40 | Receptacle Male Blades | 8 A | UL94 V-2 | IEC 320-C14 | |||||||
TE Connectivity AMP Connectors | Flange Panel Mount | Filtered (EMI RFI) - Commercial Medical | Bleed Resistor Earth Line Choke Front or Rear Side Mount | 6.3 mm | Quick Connect | 0.25 " | CSA ENEC UL | IP40 | Receptacle Male Blades | 12 A | UL94 V-2 | IEC 320-C16 | |||||||
 TE Connectivity AMP Connectors | Flange Panel Mount | Filtered (EMI RFI) - Commercial | Front or Rear Side Mount | 6.3 mm | Quick Connect | 0.25 " | CQC CSA ENEC UL | IP40 | Receptacle Male Blades | 1 A | UL94 V-2 | IEC 320-C14 | |||||||
 TE Connectivity AMP Connectors | Flange Panel Mount | Filtered (EMI RFI) - Commercial Medical | Bleed Resistor Earth Line Choke Front or Rear Side Mount | 6.3 mm | Quick Connect | 0.25 " | CQC CSA ENEC UL | IP40 | Receptacle Male Blades | 6 A | UL94 V-2 | IEC 320-C14 | |||||||
TE Connectivity AMP Connectors | Flange Panel Mount | Filtered (EMI RFI) - Commercial | Front or Rear Side Mount | 6.3 mm | Quick Connect | 0.25 " | CQC CSA ENEC UL | IP40 | Receptacle Male Blades | 12 A | UL94 V-2 | IEC 320-C14 |
