212514 Series
Mini-Fit Max Receptacle Housing, Dual Row, UL 94V-0, 12 Circuits, Glow-Wire Capable, Black
Manufacturer: Molex
Catalog
Mini-Fit Max Receptacle Housing, Dual Row, UL 94V-0, 12 Circuits, Glow-Wire Capable, Black
Beta
⌘K
Mini-Fit Max Receptacle Housing, Dual Row, UL 94V-0, 12 Circuits, Glow-Wire Capable, Black
Mini-Fit Max Receptacle Housing, Dual Row, UL 94V-0, 12 Circuits, Glow-Wire Capable, Black
Mini-Fit Max Receptacle Housing, Dual Row, UL 94V-0, 12 Circuits, Glow-Wire Capable, Black
| Part | Contact Termination | Row Spacing | Row Spacing | Insulation Material | Number of Rows [custom] | Connector Type | Features | Operating Temperature [Min] | Operating Temperature [Max] | Mounting Type | Fastening Type | Number of Positions | Contact Type | Color | Pitch | Pitch |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Molex | Crimp | 0.165 in | 4.2 mm | Nylon Polyamide (PA) | 2 | Receptacle | Glow Wire Compliant | -40 C | 105 ░C | Free Hanging (In-Line) | Latch Lock | 8 | Female Socket | Black | 0.165 in | 4.2 mm |
 Molex | Crimp | 0.165 in | 4.2 mm | Nylon Polyamide (PA) | 2 | Receptacle | Glow Wire Compliant | -40 C | 105 ░C | Free Hanging (In-Line) | Latch Lock | 4 | Female Socket | Black | 0.165 in | 4.2 mm |
 Molex | Crimp | 0.165 in | 4.2 mm | Nylon Polyamide (PA) | 2 | Receptacle | Glow Wire Compliant | -40 C | 105 ░C | Free Hanging (In-Line) | Latch Lock | 12 | Female Socket | Black | 0.165 in | 4.2 mm |
