1624R Series
Manufacturer: Belden Inc.
Beta
⌘K
CABLE CAT5 8COND 24AWG BLU 1000'
| Part | Shield Coverage | Shield Material | Number of Conductors | Conductor Strand | Length [x] | Length [x] | Conductor Insulation | Conductor Insulation | Jacket Color | Conductor Material | Usage | Ratings | Jacket (Insulation) Material | Length | Length | Features | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] | Shield Type | Cable Type | Wire Gauge |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Belden Inc. | 100 % | Aluminum | 8 | Solid | 100 ft | 30.5 m | Polyolefin | PO | Blue | Copper Bare | Network | UL Style CMR | Poly-Vinyl Chloride (PVC) Riser | 15.24 m 304.8 m | 50 ft 1000 ft | Drain Wire | 6.6 mm | 0.26 in | Foil | Multi-Pair Cat5 | 24 AWG |
 Belden Inc. | 100 % | Aluminum | 8 | Solid | Polyolefin | PO | Gray | Copper Bare | Network | UL Style CMR | Poly-Vinyl Chloride (PVC) Riser | 304.8 m | 1000 ft | Drain Wire | 6.6 mm | 0.26 in | Foil | Multi-Pair Cat5 | 24 AWG | ||
Belden Inc. | 100 % | Aluminum | 8 | Solid | Polyolefin | PO | Green | Copper Bare | Network | UL Style CMR | Poly-Vinyl Chloride (PVC) Riser | 304.8 m | 1000 ft | Drain Wire | 6.6 mm | 0.26 in | Foil | Multi-Pair Cat5 | 24 AWG | ||
Belden Inc. | 100 % | Aluminum | 8 | Solid | Polyolefin | PO | Red | Copper Bare | Network | UL Style CMR | Poly-Vinyl Chloride (PVC) Riser | 304.8 m | 1000 ft | Drain Wire | 6.6 mm | 0.26 in | Foil | Multi-Pair Cat5 | 24 AWG | ||
Belden Inc. | 100 % | Aluminum | 8 | Solid | Polyolefin | PO | Gray | Copper Bare | Network | UL Style CMR | Poly-Vinyl Chloride (PVC) Riser | 304.8 m | 1000 ft | Drain Wire | 6.6 mm | 0.26 in | Foil | Multi-Pair Cat5 | 24 AWG |
