SI86S662 Series

Catalog

2.5 KVRMS ISOLATOR, 6 UNIDIRECTI

Part	Voltage - Isolation	Operating Temperature [Max]	Operating Temperature [Min]	Rise / Fall Time (Typ) [custom]	Rise / Fall Time (Typ) [custom]	Common Mode Transient Immunity (Min) [Min]	Supplier Device Package	Grade	Qualification	Inputs - Side 1/Side 2 [custom]	Inputs - Side 1/Side 2 [custom]	Technology	Type	Package / Case	Package / Case [x]	Package / Case [y]	Mounting Type	Data Rate	Propagation Delay tpLH / tpHL (Max) [custom]	Propagation Delay tpLH / tpHL (Max) [custom]	Voltage - Supply [Min]	Voltage - Supply [Max]	Channel Type	Number of Channels [custom]	Pulse Width Distortion (Max) [Max]	Package / Case	Package / Case	Propagation Delay tpLH / tpHL (Max) [Max] [x]	Propagation Delay tpLH / tpHL (Max) [Max] [y]	Package / Case
Skyworks Solutions Inc. SI86S662BB-AU	2500 Vrms	125 °C	-40 C	2.5 ns	2.5 ns	150 kV/µs	16-QSOP	Automotive	AEC-Q100	2	4	Capacitive Coupling	SPI	16-SSOP	0.154 in	3.9 mm	Surface Mount	150 Mbps	42 ns	42 ns	2.25 V	5.5 V	Unidirectional	6	2 ns
Skyworks Solutions Inc. SI86S662BE-AS2R	6000 Vrms	125 °C	-40 C	2.5 ns	2.5 ns	150 kV/µs	16-SOIC	Automotive	AEC-Q100	2	4	Capacitive Coupling	SPI	16-SOIC			Surface Mount	150 Mbps	42 ns	42 ns	2.25 V	5.5 V	Unidirectional	6	2 ns	7.5 mm	0.295 "
Skyworks Solutions Inc. SI86S662BB-AUR	2500 Vrms	125 °C	-40 C	2.5 ns	2.5 ns	150 kV/µs	16-QSOP	Automotive	AEC-Q100	2	4	Capacitive Coupling	SPI	16-SSOP	0.154 in	3.9 mm	Surface Mount	150 Mbps	42 ns	42 ns	2.25 V	5.5 V	Unidirectional	6	2 ns
Skyworks Solutions Inc. SI86S662BB-IU	2500 Vrms	125 °C	-40 C	2.5 ns	2.5 ns	100 V/ns	16-QSOP			2	4	Capacitive Coupling	General Purpose	16-SSOP	0.154 in	3.9 mm	Surface Mount	150 Mbps			2.25 V	5.5 V	Unidirectional	6	2 ns			14 ns	14 ns
Skyworks Solutions Inc. SI86S662EC-IS1R	3750 Vrms	125 °C	-40 C	2.5 ns	2.5 ns	100 V/ns	16-SOIC			2	4	Capacitive Coupling	General Purpose	16-SOIC			Surface Mount	150 Mbps			2.25 V	5.5 V	Unidirectional	6	2 ns			14 ns	14 ns	0.154 in 3.9 mm
Skyworks Solutions Inc. SI86S662EE-IS2R	6000 Vrms	125 °C	-40 C	2.5 ns	2.5 ns	100 V/ns	16-SOIC			2	4	Capacitive Coupling	General Purpose	16-SOIC			Surface Mount	150 Mbps			2.25 V	5.5 V	Unidirectional	6	2 ns	7.5 mm	0.295 "	14 ns	14 ns
Skyworks Solutions Inc. SI86S662BE-IS2R	6000 Vrms	125 °C	-40 C	2.5 ns	2.5 ns	100 V/ns	16-SOIC			2	4	Capacitive Coupling	General Purpose	16-SOIC			Surface Mount	150 Mbps			2.25 V	5.5 V	Unidirectional	6	2 ns	7.5 mm	0.295 "	14 ns	14 ns
Skyworks Solutions Inc. SI86S662EE-AS2	6000 Vrms	125 °C	-40 C	2.5 ns	2.5 ns	150 kV/µs	16-SOIC	Automotive	AEC-Q100	2	4	Capacitive Coupling	SPI	16-SOIC			Surface Mount	150 Mbps	42 ns	42 ns	2.25 V	5.5 V	Unidirectional	6	2 ns	7.5 mm	0.295 "
Skyworks Solutions Inc. SI86S662EB-AUR	2500 Vrms	125 °C	-40 C	2.5 ns	2.5 ns	150 kV/µs	16-QSOP	Automotive	AEC-Q100	2	4	Capacitive Coupling	SPI	16-SSOP	0.154 in	3.9 mm	Surface Mount	150 Mbps	42 ns	42 ns	2.25 V	5.5 V	Unidirectional	6	2 ns
Skyworks Solutions Inc. SI86S662EE-IS2	6000 Vrms	125 °C	-40 C	2.5 ns	2.5 ns	100 V/ns	16-SOIC			2	4	Capacitive Coupling	General Purpose	16-SOIC			Surface Mount	150 Mbps			2.25 V	5.5 V	Unidirectional	6	2 ns	7.5 mm	0.295 "	14 ns	14 ns
