Fixed Terminal Blocks 17P EM3923 Series
Fixed Terminal Blocks 17P EM3923 Series
| Part | Operating Temperature [Min] | Operating Temperature [Max] | Housing Material | Screw Material - Plating | Torque - Screw | Torque - Screw | Contact Material - Plating | Screw Thread | Clamp Material - Plating | Wire Termination | Current | Number of Levels | Voltage | Features | Color | Wire Gauge [Max] | Wire Gauge [Min] | Mating Orientation | Positions Per Level | Mounting Type | Pitch | Pitch |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Eaton - Electronics Division | -40 C | 105 ░C | Thermoplastic | Steel - Zinc Plated | 0.17 Nm | 1.5 Lb-In | Brass - Tin Plated | M2 | Brass - Nickel Plated | Screw - Rising Cage Clamp | 10 A | 1 | 300 VDC | Interlocking (Side) | Green | 26 AWG | 16 AWG | Horizontal with Board | 17 | Through Hole | 3.5 mm | 0.138 " |
 Eaton - Electronics Division | Screw - Rising Cage Clamp | 10 A | 1 | 300 VDC | Interlocking (Side) | Green | 26 AWG | 16 AWG | Horizontal with Board | 13 | Through Hole | 3.5 mm | 0.138 " |
