1818P Series
Manufacturer: Belden Inc.
Beta
⌘K
12 FS PR #22 FEP SLF
| Part | Shield Coverage | Shield Material | Number of Conductors | Ratings | Jacket Color | Operating Temperature [Min] | Operating Temperature [Max] | Jacket (Insulation) Material | Cable Type | Shield Type | Length | Length | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] | Usage | Conductor Insulation | Voltage | Conductor Material | Conductor Strand [custom] | Conductor Strand [custom] | Jacket (Insulation) Thickness [x] | Jacket (Insulation) Thickness [x] | Features | Wire Gauge |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Belden Inc. | 100 % | Aluminum Polyester | 24 | UL Style CMP | Black | -40 C | 105 ░C | Polyvinylidene Fluoride (PVDF) | Multi-Pair | Foil | 304.8 m | 1000 ft | 0.524 " | 13.31 mm | Audio | Fluorinated Ethylene-Propylene (FEP) | 300 VDC | Copper Tinned | 30 AWG | 7 | 0.381 mm | 0.015 in | Drain Wire Rip Cord | 22 AWG |
