8205 Series
Manufacturer: Belden Inc.
Beta
⌘K
MULTIPAIR UNSCREENED CABLE, AUDIO CONTROL, 1 PAIR, 20 AWG, 0.519 MM , 7 X 0.32MM, 498.69 FT ROHS COMPLIANT: YES
| Part | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] | Cable Type | Length | Length | Usage | Operating Temperature [Min] | Operating Temperature [Max] | Jacket Color | Conductor Insulation | Conductor Material | Jacket (Insulation) Thickness | Jacket (Insulation) Thickness | Number of Conductors | Conductor Strand [custom] | Conductor Strand [custom] | Jacket (Insulation) Material | Wire Gauge | Length [x] | Length [x] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Belden Inc. | 4.57 mm | 0.18 in | Speaker | 152.4 m | 500 ft | Audio Control Instrumentation | -20 ░C | 60 °C | Chrome | Poly-Vinyl Chloride (PVC) | Copper Tinned | 0.635 mm | 0.025 in | 2 | 28 AWG | 7 | Poly-Vinyl Chloride (PVC) | 20 AWG | ||
Belden Inc. | 4.57 mm | 0.18 in | Speaker | Audio Control Instrumentation | -20 ░C | 60 °C | Chrome | Poly-Vinyl Chloride (PVC) | Copper Tinned | 0.635 mm | 0.025 in | 2 | 28 AWG | 7 | Poly-Vinyl Chloride (PVC) | 20 AWG | 100 ft | 30.5 m |
