KTPS18 Series

Catalog

AC/DC WALL MOUNT ADAPTER 16V 19W

Part	Input Connector	Power (Watts)	Voltage - Input [Min]	Voltage - Input [Max]	Current - Output (Max) [Max]	Output Connector	Output Connector [diameter]	Output Connector [x]	Region Utilized	Applications	Input Type	Polarization	Efficiency	Voltage - Output	Form	Approval Agency	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [x]	Cord Length	Cord Length	Operating Temperature [Max]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [z]	Output Connector [custom]	Output Connector [custom]	Output Connector [custom]	Standard Number
Volgen + Furuno KTPS18-16012WA-VI-P1	NEMA 1-15P	19 W	100 VAC	240 VAC	1.2 A	Barrel Plug	2.1 mm 5.5 mm	9.5 mm	North America	ITE (Commercial)	Fixed Blade	Positive Center	Level VI	16 V	Wall Mount	cUL PSE UL	34 mm	1.34 "	2.05 "	72 mm	52 mm	2.83 "	1.5 m	59 in	40 °C
Volgen + Furuno KTPS18-07025MP-VI-P1R	Multi-Blade	18 W	100 VAC	240 VAC	2.5 A	Barrel Plug R/A			International	ITE (Commercial)	Multi-Blade (Included)	Positive Center	Level VI	7 V	Wall Mount	CB CE cUL GS PSE RCM UL		35.8 mm	65.6 mm			75 mm	1.5 m	59 in	40 °C	2.95 "	1.41 "	2.58 "	9.5 mm	5.5 mm	2.1 mm
Volgen + Furuno KTPS18-18011WA-VI-P1	NEMA 1-15P	20 W	100 VAC	240 VAC		Barrel Plug	2.1 mm 5.5 mm	9.5 mm	North America	ITE (Commercial)	Fixed Blade	Positive Center	Level VI	18 V	Wall Mount	cUL PSE UL	34 mm	1.34 "	2.05 "	72 mm	52 mm	2.83 "	1.5 m	59 in	40 °C
Volgen + Furuno KTPS18-16012MP-VI-P2	Multi-Blade	19 W	100 VAC	240 VAC	1.2 A	Barrel Plug	2.5 mm 5.5 mm	9.5 mm	International	ITE (Commercial)	Multi-Blade (Included)	Positive Center	Level VI	16 V	Wall Mount	CB CE cUL GS PSE RCM UL		35.8 mm	65.6 mm			75 mm	1.5 m	59 in	40 °C	2.95 "	1.41 "	2.58 "
Volgen + Furuno KTPS18-15013WA-VI-P2	NEMA 1-15P	20 W	100 VAC	240 VAC	1.3 A	Barrel Plug	2.5 mm 5.5 mm	9.5 mm	North America	ITE (Commercial)	Fixed Blade	Positive Center	Level VI	15 V	Wall Mount	cUL PSE UL	34 mm	1.34 "	2.05 "	72 mm	52 mm	2.83 "	1.5 m	59 in	40 °C
Volgen + Furuno KTPS18-12016WA-VI-P2	NEMA 1-15P	19 W	100 VAC	240 VAC	1.6 A	Barrel Plug	2.5 mm 5.5 mm	9.5 mm	North America	ITE (Commercial)	Fixed Blade	Positive Center	Level VI	12 V	Wall Mount	IEC	34 mm	1.34 "	2.05 "	72 mm	52 mm	2.83 "	1.5 m	59 in	40 °C							60950-1
Volgen + Furuno KTPS18-05930WA-VI-P2	NEMA 1-15P	18 W	100 VAC	240 VAC	3 A	Barrel Plug	2.5 mm 5.5 mm	9.5 mm	North America	ITE (Commercial)	Fixed Blade	Positive Center	Level VI	5.9 V	Wall Mount	cUL PSE UL	34 mm	1.34 "	2.05 "	72 mm	52 mm	2.83 "	1.5 m	59 in	40 °C
Volgen + Furuno KTPS18-09022WA-VI-P1	NEMA 1-15P	20 W	100 VAC	240 VAC	2.2 A	Barrel Plug	2.1 mm 5.5 mm	9.5 mm	International	ITE (Commercial)	Fixed Blade	Positive Center	Level VI	9 V	Wall Mount	cUL PSE UL	34 mm	1.34 "	2.05 "	72 mm	52 mm	2.83 "	1.5 m	59 in	40 °C
Volgen + Furuno KTPS18-18011MP-VI-P2	Multi-Blade	20 W	100 VAC	240 VAC		Barrel Plug	2.5 mm 5.5 mm	9.5 mm	International	ITE (Commercial)	Multi-Blade (Included)	Positive Center	Level VI	18 V	Wall Mount	CB CE cUL GS PSE RCM UL		35.8 mm	65.6 mm			75 mm	1.5 m	59 in	40 °C	2.95 "	1.41 "	2.58 "
Volgen + Furuno KTPS18-09022MP-VI-P2	Multi-Blade	20 W	100 VAC	240 VAC	2.2 A	Barrel Plug	2.5 mm 5.5 mm	9.5 mm	International	ITE (Commercial)	Multi-Blade (Included)	Positive Center	Level VI	9 V	Wall Mount	CB CE cUL GS PSE RCM UL		35.8 mm	65.6 mm			75 mm	1.5 m	59 in	40 °C	2.95 "	1.41 "	2.58 "
