RFB-1707 Series
Manufacturer: RF Industries
Beta
⌘K
BNC MALE CRIMP; 75 OHMS
| Part | Body Finish | Center Contact Plating | Dielectric Material | Operating Temperature [Min] | Operating Temperature [Max] | Body Material | Voltage Rating | Mounting Type | Connector Type | Housing Color | Fastening Type | Connector Style | Cable Group | Shield Termination | Number of Ports | Frequency - Max [Max] | Contact Termination | Impedance | Center Contact Material |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 RF Industries | Nickel | Gold | Polytetrafluoroethylene (PTFE) | -65 ░C | 165 °C | Brass | 500 V | Free Hanging (In-Line) | Plug Male Pin | Silver | Bayonet Lock | BNC | 8261 9212 Belden 8238 RG-11 | Crimp | 1 | 3 GHz | Solder | 75 Ohms | Brass |
 RF Industries | Nickel | Gold | Polyoxymethylene (POM) Acetal | -65 ░C | 85 °C | Brass | 500 V | Free Hanging (In-Line) | Plug Male Pin | Silver | Bayonet Lock | BNC | 8281B 8281F 9231 Belden 8281 | Crimp | 1 | 4 GHz | Crimp | 50 Ohms | Brass |
 RF Industries | Nickel | Gold | Polytetrafluoroethylene (PTFE) | -65 ░C | 85 °C | Brass | 500 V | Free Hanging (In-Line) | Plug Male Pin | Silver | Bayonet Lock | BNC | 179 179A 187 187A RG-161 | Crimp | 1 | 4 GHz | Crimp Solder | 75 Ohms | Brass |
 RF Industries | Silver | Gold | Polytetrafluoroethylene (PTFE) | -65 ░C | 85 °C | Brass | 500 V | Free Hanging (In-Line) | Plug Male Pin | Silver | Bayonet Lock | BNC | Crimp | 1 | 4 GHz | Crimp | 75 Ohms | Brass |
