857-026 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 52POS 0.156
| Part | Material - Insulation | Card Thickness [Max] | Card Thickness [Min] | Operating Temperature [Max] | Operating Temperature [Min] | Contact Finish | Contact Type | Contact Material | Color | Number of Positions/Bay/Row | Mounting Type | Flange Feature [diameter] | Flange Feature | Flange Feature [diameter] | Number of Rows [custom] | Card Type | Number of Positions | Contact Finish Thickness | Contact Finish Thickness | Pitch | Pitch | Gender | Read Out | Termination | Termination Rows | Termination Rows [custom] | Number of Rows |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Gold | Semi Bellows | Copper Alloy | Black | 26 | Right Angle Through Hole | 0.116 " | Floating Bobbin Flush Mount | 2.95 mm | 2 | Non Specified - Dual Edge | 52 | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | Female | Dual | Solder | 1 | ||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Gold | Semi Bellows | Copper Alloy | Black | 13 | Through Hole | 0.116 " | Floating Bobbin Flush Mount | 2.95 mm | 2 | Non Specified - Dual Edge | 26 | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | Female | Dual | Solder Eyelet(s) | 2 | ||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Tin | Semi Bellows | Copper Alloy | Black | 13 | Through Hole | Flush Mount M3 Threaded Insert Top Opening | 2 | Non Specified - Dual Edge | 26 | 3.96 mm | 0.156 in | Female | Dual | Solder Eyelet(s) | 2 | ||||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Tin | Semi Bellows | Copper Alloy | Black | 13 | Through Hole | 4-40 Flush Mount Threaded Insert Top Opening | 2 | Non Specified - Dual Edge | 26 | 3.96 mm | 0.156 in | Female | Dual | Solder | 2 | ||||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Gold | Semi Bellows | Copper Alloy | Black | 26 | Through Hole | 4-40 Flush Mount Threaded Insert Top Opening | Non Specified - Single Edge | 26 | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | Female | Single | Solder | 1 | 1 | ||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Tin | Semi Bellows | Copper Alloy | Black | 26 | Right Angle Through Hole | Flush Mount M3 Threaded Insert Top Opening | 2 | Non Specified - Dual Edge | 52 | 3.96 mm | 0.156 in | Female | Dual | Solder | 1 | ||||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Gold | Semi Bellows | Copper Alloy | Black | 26 | Through Hole | Flush Mount M3 Threaded Insert Top Opening | Non Specified - Single Edge | 26 | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | Female | Single | Wire Wrap | 1 | 1 | ||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Gold | Semi Bellows | Copper Alloy | Black | 26 | Through Hole | 0.128 " | Flush Mount Top Opening Unthreaded | 3.25 mm | Non Specified - Single Edge | 26 | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | Female | Single | Solder | 1 | 1 | ||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Tin | Semi Bellows | Copper Alloy | Black | 26 | Right Angle Through Hole | 0.116 " | Floating Bobbin Flush Mount | 2.95 mm | Non Specified - Single Edge | 26 | 3.96 mm | 0.156 in | Female | Single | Solder | 1 | 1 | ||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Tin | Semi Bellows | Copper Alloy | Black | 13 | Right Angle Through Hole | 4-40 Flush Mount Threaded Insert Top Opening | 2 | Non Specified - Dual Edge | 26 | 3.96 mm | 0.156 in | Female | Single | Solder | 2 |
