Circular Push Pull Connectors FIXED RECEPTACLE NUT FIXING
Circular Push Pull Connectors FIXED RECEPTACLE NUT FIXING
| Part | Contact Finish - Mating | Ingress Protection | Features | Number of Positions | Connector Type | Contact Material | Current Rating (Amps) | Material Flammability Rating | Insert Material | Shielding | Orientation | Shell Size - Insert | Operating Temperature [Min] | Operating Temperature [Max] | Primary Material | Cable Opening [Min] [custom] | Cable Opening [Max] [custom] | Cable Opening [Max] [custom] | Cable Opening [Min] [custom] | Color | Shell Material | Backshell Material, Plating | Mounting Type | Shell Finish | Fastening Type | Cable Opening [custom] | Cable Opening [custom] | For Use With/Related Products | Accessory Type | Material |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
LEMO | Gold | IP50 | Insert Only Requires Shell | 1 | Insert Male Pins | Brass | 4 A | UL94 V-0 | Polyetheretherketone (PEEK) | Shielded | Keyed | 403 | -55 °C | 250 °C | ||||||||||||||||
Gold | IP50 | Backshell | 1 | Male Pins Plug | Brass | 4 A | UL94 V-0 | Polyetheretherketone (PEEK) | Shielded | Keyed | 403 | -55 °C | 250 °C | Metal | 0.126 in | 4.2 mm | 0.165 in | 3.2 mm | Silver | Brass | Brass Chrome | Free Hanging (In-Line) | Chrome | Push-Pull | ||||||
Gold | IP50 | Backshell | 1 | Male Pins Plug | Brass | 4 A | Polytetrafluoroethylene (PTFE) | Shielded | Keyed | 403 | -55 °C | 250 °C | Metal | 0.126 in | 4.2 mm | 0.165 in | 3.2 mm | Silver | Brass | Brass Chrome | Free Hanging (In-Line) | Chrome | Push-Pull | |||||||
Gold | IP50 | Backshell | 1 | Female Sockets Plug | Bronze | 4 A | Polytetrafluoroethylene (PTFE) | Shielded | Keyed | 403 | -55 °C | 250 °C | Metal | Silver | Brass | Brass Chrome | Free Hanging (In-Line) | Chrome | Push-Pull | |||||||||||
Gold | IP50 | Backshell | 1 | Male Pins Plug | Brass | 4 A | Polytetrafluoroethylene (PTFE) | Shielded | Keyed | 403 | -55 °C | 250 °C | Metal | Silver | Brass | Brass Chrome | Free Hanging (In-Line) | Chrome | Push-Pull | |||||||||||
Gold | IP50 | Backshell | 1 | Male Pins Plug | Brass | 4 A | UL94 V-0 | Polyetheretherketone (PEEK) | Shielded | Keyed | 403 | -55 °C | 250 °C | Metal | Silver | Brass | Brass Chrome | Free Hanging (In-Line) | Chrome | Push-Pull | 2.2 mm 3.2 mm | 0.087 in 0.126 in | ||||||||
LEMO | Gold | IP50 | Insert Only Requires Shell | 1 | Insert Male Pins | Brass | 4 A | Polytetrafluoroethylene (PTFE) | Shielded | Keyed | 403 | -55 °C | 250 °C | |||||||||||||||||
LEMO | Silver | 0S Series Connector | Back-Nut Collet | Brass | ||||||||||||||||||||||||||
Gold | IP50 | Backshell | 1 | Male Pins Plug | Brass | 4 A | Polytetrafluoroethylene (PTFE) | Shielded | Keyed | 403 | -55 °C | 250 °C | Metal | Silver | Brass | Brass Chrome | Free Hanging (In-Line) | Chrome | Push-Pull |
