SFV20R Series
Manufacturer: Amphenol ICC (FCI)
Beta
⌘K
CONN FFC FPC TOP 20POS 0.5MM R/A
| Part | Actuator Color | Mating Cycles | Current Rating (Amps) | Housing Color | Flat Flex Type | Housing Material | Contact Material | Termination | Connector/Contact Type | Operating Temperature [Min] | Operating Temperature [Max] | Actuator Material | Pitch | Pitch | Number of Positions | Mounting Type | Voltage Rating | FFC, FCB Thickness | Locking Feature | Cable End Type | Material Flammability Rating | Height Above Board [z] | Height Above Board [z] | Contact Finish | Features | FFC, FCB Thickness [custom] | FFC, FCB Thickness [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Amphenol ICC (FCI) | Beige | 20 | 0.5 A | Black | FFC FPC | Glass Filled Halogen Free Liquid Crystal Polymer (LCP) | Phosphor Bronze | Solder | Contacts Top | -55 C | 105 ░C | Polyphenylene Sulfide (PPS) Glass Filled Halogen Free | 0.02 " | 0.5 mm | 20 | Right Angle Surface Mount | 50 V | 0.3 mm | Slide Lock | Tapered | UL94 V-0 | 0.071 in | 1.8 mm | Gold | |||
 Amphenol ICC (FCI) | Black | 0.5 A | Black | FPC | Glass Filled Nylon Polyamide (PA) | Phosphor Bronze | Solder | Contacts Top | -55 C | 105 ░C | Polyphenylene Sulfide (PPS) Glass Filled | 0.02 " | 0.5 mm | 20 | Right Angle Surface Mount | 50 V | 0.33 mm | Slide Lock | Notched | UL94 V-0 | 0.071 in | 1.8 mm | Tin | Solder Retention Zero Insertion Force (ZIF) | |||
 Amphenol ICC (FCI) | Brown | 0.5 A | Black | FFC FPC | Glass Filled Nylon Polyamide (PA) | Phosphor Bronze | Solder | Contacts Top | -55 C | 105 ░C | Polyphenylene Sulfide (PPS) Glass Filled | 0.02 " | 0.5 mm | 20 | Right Angle Surface Mount | 50 V | Slide Lock | Straight Tapered | UL94 V-0 | 0.071 in | 1.8 mm | Tin | Solder Retention Zero Insertion Force (ZIF) | 0.3 mm | 0.33 mm | ||
 Amphenol ICC (FCI) | FFC FPC | Glass Filled Halogen Free Nylon Polyamide (PA) | Solder | Contacts Bottom | Polyphenylene Sulfide (PPS) Glass Filled Halogen Free | 0.02 " | 0.5 mm | 20 | Right Angle Surface Mount | Slide Lock | Straight Tapered | 0.071 in | 1.8 mm | 0.3 mm | 0.33 mm | ||||||||||||
Amphenol ICC (FCI) | Black | 20 | 0.5 A | Black | FFC FPC | Glass Filled Halogen Free Liquid Crystal Polymer (LCP) | Phosphor Bronze | Solder | Contacts Bottom | -55 C | 105 ░C | Polyphenylene Sulfide (PPS) Glass Filled Halogen Free | 0.02 " | 0.5 mm | 20 | Right Angle Surface Mount | 50 V | Slide Lock | Straight Tapered | UL94 V-0 | 0.071 in | 1.8 mm | Gold | Solder Retention Zero Insertion Force (ZIF) | 0.3 mm | 0.33 mm | |
 Amphenol ICC (FCI) | Black | 20 | 0.5 A | Black | FPC | Glass Filled Halogen Free Liquid Crystal Polymer (LCP) | Phosphor Bronze | Solder | Contacts Bottom | -55 C | 105 ░C | Polyphenylene Sulfide (PPS) Glass Filled Halogen Free | 0.02 " | 0.5 mm | 20 | Right Angle Surface Mount | 50 V | Slide Lock | Straight Tapered | UL94 V-0 | 0.071 in | 1.8 mm | Tin | 0.3 mm | 0.33 mm | ||
Amphenol ICC (FCI) | Brown | 20 | 0.5 A | Black | FFC FPC | Glass Filled Nylon Polyamide (PA) | Phosphor Bronze | Solder | Contacts Top | -55 C | 105 ░C | Polyphenylene Sulfide (PPS) Glass Filled | 0.02 " | 0.5 mm | 20 | Right Angle Surface Mount | 50 V | Slide Lock | Straight Tapered | UL94 V-0 | 0.071 in | 1.8 mm | Tin Alloy | Solder Retention Zero Insertion Force (ZIF) | 0.3 mm | 0.33 mm | |
Amphenol ICC (FCI) | Brown | 20 | 0.5 A | Black | FFC FPC | Glass Filled Nylon Polyamide (PA) | Phosphor Bronze | Solder | Contacts Bottom | -55 C | 105 ░C | Polyphenylene Sulfide (PPS) Glass Filled | 0.02 " | 0.5 mm | 20 | Right Angle Surface Mount | 50 V | Slide Lock | Straight Tapered | UL94 V-0 | 0.071 in | 1.8 mm | Tin Alloy | Solder Retention Zero Insertion Force (ZIF) | 0.3 mm | 0.33 mm | |
 Amphenol ICC (FCI) | Beige | 20 | 0.5 A | Black | FPC | Glass Filled Halogen Free Liquid Crystal Polymer (LCP) | Phosphor Bronze | Solder | Contacts Top | -55 C | 105 ░C | Polyphenylene Sulfide (PPS) Glass Filled Halogen Free | 0.02 " | 0.5 mm | 20 | Right Angle Surface Mount | 50 V | 0.3 mm | Slide Lock | Tapered | UL94 V-0 | 0.071 in | 1.8 mm | Gold | |||
 Amphenol ICC (FCI) | Brown | 20 | 0.5 A | Black | FPC | Glass Filled Halogen Free Liquid Crystal Polymer (LCP) | Phosphor Bronze | Solder | Contacts Bottom | -55 C | 105 ░C | Polyphenylene Sulfide (PPS) Glass Filled Halogen Free | 0.02 " | 0.5 mm | 20 | Right Angle Surface Mount | 50 V | Slide Lock | Notched | UL94 V-0 | 0.071 in | 1.8 mm | Gold | 0.3 mm | 0.33 mm |
