837-007 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 7POS 0.156
| Part | Termination Rows | Material - Insulation | Card Thickness [Max] | Card Thickness [Min] | Gender | Read Out | Number of Rows | Contact Finish | Contact Material | Color | Pitch | Pitch | Contact Finish Thickness | Contact Finish Thickness | Flange Feature | Card Type | Number of Positions/Bay/Row | Number of Positions | Mounting Type | Termination | Operating Temperature [Max] | Operating Temperature [Min] | Contact Type | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Single | 1 | Gold | Copper Alloy | Green | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | Flush Mount M3 Threaded Insert Top Opening | Non Specified - Single Edge | 7 | 7 | Through Hole | Solder | 125 °C | -40 C | Cantilever | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Single | 1 | Gold | Copper Alloy | Green | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | 4-40 Flush Mount Threaded Insert Top Opening | Non Specified - Single Edge | 7 | 7 | Through Hole | Wire Wrap | 125 °C | -40 C | Cantilever | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Single | 1 | Gold | Copper Alloy | Green | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | Non Specified - Single Edge | 7 | 7 | Through Hole | Solder | 125 °C | -40 C | Cantilever | 0.156 " | 3.96 mm | |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Single | 1 | Gold | Copper Alloy | Green | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | Floating Bobbin Top Mount Opening | Non Specified - Single Edge | 7 | 7 | Through Hole | Solder Eyelet(s) | 125 °C | -40 C | Cantilever | 0.116 " | 2.95 mm |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Single | 1 | Gold | Copper Alloy | Green | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | Flush Mount Side Opening Unthreaded | Non Specified - Single Edge | 7 | 7 | Through Hole | Solder | 125 °C | -40 C | Cantilever | 0.128 " | 3.25 mm |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Single | 1 | Gold | Copper Alloy | Green | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | Floating Bobbin Flush Mount | Non Specified - Single Edge | 7 | 7 | Right Angle Through Hole | Solder | 125 °C | -40 C | Cantilever | 0.116 " | 2.95 mm |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Single | 1 | Gold | Copper Alloy | Green | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | M3 Threaded Insert Top Mount Opening | Non Specified - Single Edge | 7 | 7 | Through Hole | Solder Eyelet(s) | 125 °C | -40 C | Cantilever | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Single | 1 | Gold | Copper Alloy | Green | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | Non Specified - Single Edge | 7 | 7 | Through Hole | Solder | 125 °C | -40 C | Cantilever | |||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Single | 1 | Gold | Copper Alloy | Green | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | 4-40 Flush Mount Threaded Insert Top Opening | Non Specified - Single Edge | 7 | 7 | Through Hole | Solder | 125 °C | -40 C | Cantilever | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Single | 1 | Gold | Copper Alloy | Green | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | Non Specified - Single Edge | 7 | 7 | Right Angle Through Hole | Solder | 125 °C | -40 C | Cantilever |
