JG0 Series
Modular Connectors / Ethernet Connectors 1X6 TAB UP 8-CORE W/
Manufacturer: Pulse Electronics
Catalog
Modular Connectors / Ethernet Connectors 1X6 TAB UP 8-CORE W/
Beta
⌘K
Modular Connectors / Ethernet Connectors 1X6 TAB UP 8-CORE W/
Modular Connectors / Ethernet Connectors 1X6 TAB UP 8-CORE W/
Modular Connectors / Ethernet Connectors 1X6 TAB UP 8-CORE W/
| Part | Contact Finish | Number of Cores per Jack | Height Above Board | Height Above Board | Applications | Shielding | Features | LED Color | Contact Material | Operating Temperature [Max] | Operating Temperature [Min] | Connector Type | Tab Direction | Number of Ports [custom] | Mounting Type | Number of Rows | Orientation | Termination | Housing Material | Shield Material | Contact Finish Thickness | Contact Finish Thickness | Number of Ports |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Pulse Electronics | Gold | 8 | 0.545 in | 13.84 mm | 10/100/1000 Base-T AutoMDIX | EMI Finger Shielded | Board Guide | Green - Green | Phosphor Bronze | 70 °C | 0 °C | RJ45 | Up | 6 | Through Hole | 1 | 90 ° | Solder | |||||
 Pulse Electronics | Gold | 8 | 0.545 in | 13.84 mm | 10/100/1000 Base-T AutoMDIX | EMI Finger Shielded | Board Guide | Green - Green | Phosphor Bronze | 70 °C | 0 °C | RJ45 | Up | Through Hole | 1 | 90 ° | Solder | Thermoplastic | Brass | 30 Áin | 0.76 Ám | 4 |
