6+6 POS. MALE DIL VERTICAL SMT CONN. NO LATCHES (P+P) ROHS COMPLIANT: YES

Part	Contact Finish Thickness - Post [custom]	Contact Finish Thickness - Post [custom]	Mated Stacking Heights	Shrouding	Number of Positions	Contact Type	Contact Finish - Mating	Pitch - Mating	Pitch - Mating	Termination	Insulation Material	Fastening Type	Operating Temperature [Min]	Operating Temperature [Max]	Voltage Rating	Number of Rows [custom]	Style	Features	Number of Positions Loaded	Current Rating (Amps)	Row Spacing - Mating	Row Spacing - Mating	Mounting Type	Contact Shape	Connector Type	Insulation Color	Contact Material	Insulation Height	Insulation Height	Material Flammability Rating	Contact Finish Thickness - Mating [custom]	Contact Finish Thickness - Mating [custom]	Contact Finish - Post	Mated Stacking Heights [z]	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Number of Positions [custom]
Harwin Inc. M80-8261242P	118.1 µin	3 µm	7.85 mm 8.45 mm 10.5 mm 14.25 mm	Shrouded - 4 Wall	12	Male Pin	Gold	0.079 "	2 mm	Solder	Polyphenylene Sulfide (PPS) Glass Filled	Latch Holder	-55 C	125 °C	800 V	2	Board to Board Cable	Pick and Place	All	2.2 A	2 mm	0.079 in	Surface Mount	Circular	Header	Black	Phosphor Bronze	5.2 mm	0.205 "	UL94 V-0	29.5 µin	0.75 µm	Tin
Harwin Inc. M80-8261622P				Shrouded - 4 Wall	16	Male Pin	Gold	0.079 "	2 mm	Solder	Polyphenylene Sulfide (PPS)	Latch Holder	-55 C	125 °C	800 VAC	2	Board to Board Cable	Pick and Place	All	2.2 A	2 mm	0.079 in	Surface Mount	Circular	Header	Black	Phosphor Bronze	5.2 mm	0.205 "	UL94 V-0	29.5 µin	0.75 µm	Tin-Lead	7.93 mm 8.53 mm	12 µin	0.3 µm
Harwin Inc. M80-8261642	118.1 µin	3 µm	7.85 mm 8.45 mm 10.5 mm 14.25 mm	Shrouded - 4 Wall	16	Male Pin	Gold	0.079 "	2 mm	Solder	Polyphenylene Sulfide (PPS) Glass Filled	Latch Holder	-55 C	125 °C	800 V	2	Board to Board Cable		All	2.2 A	2 mm	0.079 in	Surface Mount	Circular	Plug	Black	Phosphor Bronze	5.2 mm	0.205 "	UL94 V-0	29.5 µin	0.75 µm	Tin
Harwin Inc. M80-8261445			7.85 mm 8.45 mm 10.5 mm 14.25 mm	Shrouded - 4 Wall	14	Male Pin	Gold	0.079 "	2 mm	Solder	Polyphenylene Sulfide (PPS) Glass Filled	Latch Holder	-55 C	125 °C	800 V	2	Board to Board Cable		All	2.2 A	2 mm	0.079 in	Surface Mount	Circular	Header	Black	Phosphor Bronze	5.2 mm	0.205 "	UL94 V-0	29.5 µin	0.75 µm	Gold
Harwin Inc. M80-8261042P	118.1 µin	3 µm	7.85 mm 8.45 mm 10.5 mm 14.25 mm	Shrouded - 4 Wall	10	Male Pin	Gold	0.079 "	2 mm	Solder	Polyphenylene Sulfide (PPS) Glass Filled	Latch Holder	-55 C	125 °C	800 V	2	Board to Board Cable	Pick and Place	All	2.2 A	2 mm	0.079 in	Surface Mount	Circular	Header	Black	Phosphor Bronze	5.2 mm	0.205 "	UL94 V-0	29.5 µin	0.75 µm	Tin
Harwin Inc. M80-8260642	118.1 µin	3 µm	7.85 mm 8.45 mm 10.5 mm 14.25 mm	Shrouded - 4 Wall	6	Male Pin	Gold	0.079 "	2 mm	Solder	Polyphenylene Sulfide (PPS) Glass Filled	Latch Holder	-55 C	125 °C	800 V	2	Board to Board Cable		All	2.2 A	2 mm	0.079 in	Surface Mount	Circular	Plug	Black	Phosphor Bronze	5.2 mm	0.205 "	UL94 V-0	29.5 µin	0.75 µm	Tin
Harwin Inc. M80-8260622P				Shrouded - 4 Wall	6	Male Pin	Gold	0.079 "	2 mm	Solder	Polyphenylene Sulfide (PPS) Glass Filled	Latch Holder	-55 C	125 °C	800 VAC	2	Board to Board Cable		All	2.2 A	2 mm	0.079 in	Surface Mount	Circular	Header	Black	Phosphor Bronze	5.2 mm	0.205 "	UL94 V-0	29.5 µin	0.75 µm	Tin-Lead	7.93 mm 8.53 mm	12 µin	0.3 µm
Harwin Inc. M80-8260442P	118.1 µin	3 µm	7.85 mm 8.45 mm 10.5 mm 14.25 mm	Shrouded - 4 Wall	4	Male Pin	Gold	0.079 "	2 mm	Solder	Polyphenylene Sulfide (PPS) Glass Filled	Latch Holder	-55 C	125 °C	800 V	2	Board to Board Cable	Pick and Place	All	2.2 A	2 mm	0.079 in	Surface Mount	Circular	Header	Black	Phosphor Bronze	5.2 mm	0.205 "	UL94 V-0	29.5 µin	0.75 µm	Tin
Harwin Inc. M80-8263442P	118.1 µin	3 µm	7.85 mm 8.45 mm 10.5 mm 14.25 mm	Shrouded - 4 Wall		Male Pin	Gold	0.079 "	2 mm	Solder	Polyphenylene Sulfide (PPS) Glass Filled	Latch Holder	-55 C	125 °C	800 V	2	Board to Board Cable	Pick and Place	All	2.2 A	2 mm	0.079 in	Surface Mount	Circular	Header	Black	Phosphor Bronze	5.2 mm	0.205 "	UL94 V-0	29.5 µin	0.75 µm	Tin				34
Harwin Inc. M80-8262042P	118.1 µin	3 µm	7.85 mm 8.45 mm 10.5 mm 14.25 mm	Shrouded - 4 Wall	20	Male Pin	Gold	0.079 "	2 mm	Solder	Polyphenylene Sulfide (PPS) Glass Filled	Latch Holder	-55 C	125 °C	800 V	2	Board to Board Cable	Pick and Place	All	2.2 A	2 mm	0.079 in	Surface Mount	Circular	Header	Black	Phosphor Bronze	5.2 mm	0.205 "	UL94 V-0	29.5 µin	0.75 µm	Tin
