RJE73188 Series
Manufacturer: Amphenol ICC (Commercial Products)
Beta
⌘K
CONN MOD JACK 8P8C R/A SHLD
| Part | Contact Finish Thickness | Contact Finish Thickness | Operating Temperature [Min] | Operating Temperature [Max] | Housing Material | Connector Type | Number of Rows | Orientation | Contact Finish | Contact Material | LED Color | Number of Ports | Shielding | Features | Number of Positions/Contacts | Termination | Tab Direction | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Amphenol ICC (Commercial Products) | 0.152 Ám | 6 Áin | -55 C | 85 °C | Thermoplastic | Jack | 1 | 90 ° | Gold | Phosphor Bronze | Green - Green | 1 | Shielded | Board Guide | 8p8c (RJ45 Ethernet) | Solder | Down | Through Hole |
 Amphenol ICC (Commercial Products) | 0.152 Ám | 6 Áin | -55 C | 85 °C | Thermoplastic | Jack | 1 | 90 ° | Gold | Phosphor Bronze | Green - Yellow | 1 | EMI Finger Shielded | Board Guide | 8p8c (RJ45 Ethernet) | Solder | Down | Through Hole |
Amphenol ICC (Commercial Products) | 0.76 Ám | 30 Áin | -55 C | 85 °C | Thermoplastic | Jack | 1 | 90 ° | Gold | Phosphor Bronze | Green - Yellow | 1 | EMI Finger Shielded | Board Guide | 8p8c (RJ45 Ethernet) | Solder | Down | Through Hole |
Amphenol ICC (Commercial Products) | 1.27 µm | 50 µin | -55 C | 85 °C | Thermoplastic | Jack | 1 | 90 ° | Gold | Phosphor Bronze | Green Red | 1 | Shielded | Board Guide | 8p8c (RJ45 Ethernet) | Solder | Down | Through Hole |
Amphenol ICC (Commercial Products) | 1.27 µm | 50 µin | -55 C | 85 °C | Thermoplastic | Jack | 1 | 90 ° | Gold | Phosphor Bronze | Orange Yellow - Green | 1 | Shielded | Board Guide | 8p8c (RJ45 Ethernet) | Solder | Down | Through Hole |
Amphenol ICC (Commercial Products) | 0.76 Ám | 30 Áin | -55 C | 85 °C | Thermoplastic | Jack | 1 | 90 ° | Gold | Phosphor Bronze | 1 | Shielded | Board Guide | 8p8c (RJ45 Ethernet) | Solder | Down | Through Hole | |
 Amphenol ICC (Commercial Products) | 1.27 µm | 50 µin | -55 C | 85 °C | Thermoplastic | Jack | 1 | 90 ° | Gold | Phosphor Bronze | Green Yellow | 1 | EMI Finger Shielded | Board Guide | 8p8c (RJ45 Ethernet) | Solder | Down | Through Hole |
Amphenol ICC (Commercial Products) | 0.152 Ám | 6 Áin | -55 C | 85 °C | Thermoplastic | Jack | 1 | 90 ° | Gold | Phosphor Bronze | Green Yellow - Green | 1 | Shielded | Board Guide | 8p8c (RJ45 Ethernet) | Solder | Down | Through Hole |
 Amphenol ICC (Commercial Products) | 0.76 Ám | 30 Áin | -55 C | 85 °C | Thermoplastic | Jack | 1 | 90 ° | Gold | Phosphor Bronze | Yellow - Green | 1 | EMI Finger Shielded | Board Guide | 8p8c (RJ45 Ethernet) | Solder | Down | Through Hole |
Amphenol ICC (Commercial Products) | 0.38 µm | 15 µin | -55 C | 85 °C | Thermoplastic | Jack | 1 | 90 ° | Gold | Phosphor Bronze | Green Yellow - Green | 1 | EMI Finger Shielded | Board Guide | 8p8c (RJ45 Ethernet) | Solder | Down | Through Hole |
