S18-2V Series
Manufacturer: BANNER ENGINEERING
Beta
⌘K
PHOTOELECTRIC SENSOR, 750MM, 624NM RED LED, DIGITAL, 4 PIN M12 EURO CONNECTOR, 10-30VDC
| Part | Ingress Protection | Operating Temperature [Max] | Operating Temperature [Min] | Voltage - Supply [Min] | Voltage - Supply [Max] | Adjustment Type | Light Source | Sensing Distance | Sensing Distance | Response Time | Sensing Method | Connection Method | Output Configuration | Cable Length | Cable Length |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 BANNER ENGINEERING | IEC IP67 IP67 IEC | 70 °C | -40 C | 10 VDC | 30 VDC | Adjustable Potentiometer | Red LED | 750 mm | 29.528 " | 1.5 ms | Diffuse | Connector | PNP - Dark-ON/Light-ON | ||
 BANNER ENGINEERING | IEC IP67 IP67 IEC | 70 °C | -40 C | 10 VDC | 30 VDC | Adjustable Potentiometer | Red LED | 750 mm | 29.528 " | 1.5 ms | Diffuse | Connector | PNP - Dark-ON/Light-ON | ||
 BANNER ENGINEERING | IEC IEC IP67 IP67 NEMA 6P | 70 °C | -40 C | 10 VDC | 30 VDC | Adjustable Potentiometer | LED | 25 m | 82.02 ' | 1.5 ms | Through-Beam | Cable | PNP - Dark-ON/Light-ON - Selectable | 78.74 " | 2 m |
 BANNER ENGINEERING | IEC IP67 IP67 IEC | 70 °C | -40 C | 10 VDC | 30 VDC | Red LED | 6 m | 236.22 " | 1.5 ms | Polarized Retroreflective | Cable | NPN - Dark-ON/Light-ON | 78.74 " | 2 m | |
 BANNER ENGINEERING | IEC IEC IP67 IP67 NEMA 6P | 70 °C | -40 C | 10 VDC | 30 VDC | Red (624nm) | 15 cm | 5.906 " | 1.5 ms | Background Suppression | Cable | PNP - Dark-ON/Light-ON - Selectable | 78.74 " | 2 m | |
 BANNER ENGINEERING | IEC IEC IP67 IP67 NEMA 6P | 70 °C | -40 C | 10 VDC | 30 VDC | LED | 25 m | 82.02 ' | 1.5 ms | Through-Beam | Cable | PNP - Dark-ON/Light-ON - Selectable | 78.74 " | 2 m | |
 BANNER ENGINEERING | IEC IEC IP67 IP67 NEMA 6P | 70 °C | -40 C | 10 VDC | 30 VDC | Red LED | 75 mm | 2.953 in | 1.5 ms | Background Suppression | Connector | PNP - Dark-ON/Light-ON - Selectable | |||
 BANNER ENGINEERING | IEC IP67 IP67 IEC | 70 °C | -40 C | 10 VDC | 30 VDC | Red LED | 6 m | 236.22 " | 1.5 ms | Polarized Retroreflective | Connector | PNP - Dark-ON/Light-ON | |||
 BANNER ENGINEERING | IEC IEC IP67 IP67 NEMA 6P | 70 °C | -40 C | 10 VDC | 30 VDC | Adjustable Potentiometer | Red (624nm) | 30 cm | 11.811 " | 1.5 ms | Diffuse | Cable | PNP - Dark-ON/Light-ON - Selectable | 78.74 " | 2 m |
 BANNER ENGINEERING | IEC IP67 IP67 IEC | 70 °C | -40 C | 10 VDC | 30 VDC | Adjustable Potentiometer | Red LED | 750 mm | 29.528 " | 1.5 ms | Diffuse | Cable | NPN - Dark-ON/Light-ON | 78.74 " | 2 m |
