HCBB75W Series
Manufacturer: SL POWER / Advanced Energy
Beta
⌘K
AC/DC POWER SUPPLY TRIPLE-OUT 5V/12V TO 15V/-12V TO 15V 6A/1.7A/1.7A 288W CASE CBB
| Part | Voltage - Output 1 | Size / Dimension [x] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [z] | Approval Agency | Type | Mounting Type | Voltage - Output 3 | Operating Temperature [Max] | Operating Temperature [Min] | Current - Output 1 | Number of Outputs | Current - Output 3 | Voltage - Input [Min] | Voltage - Input [Max] | Power (Watts) | Features | Applications | Voltage - Output 2 | Current - Output 2 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 SL POWER / Advanced Energy | 5 V | 279.4 mm | 11 in | 124 mm | 69.9 mm | 4.88 in | 2.75 in | CE cURus TUV | Linear | Chassis Mount | -12 V | 70 °C | 0 °C | 6 A | 3 | 1.7 A | 100 VAC | 240 VAC | 71 W | Adjustable Output Remote Sense Universal Input | ITE (Commercial) | 12 V | 1.7 A |
