895-061 Series
Manufacturer: EDAC Inc.
Catalog
CONN EDGE SINGLE FML 61POS 0.100
...
| Part | Contact Finish | Read Out | Color | Termination | Number of Positions | Operating Temperature [Max] | Operating Temperature [Min] | Contact Finish Thickness | Contact Finish Thickness | Contact Material | Number of Rows | Material - Insulation | Contact Type | Number of Positions/Bay/Row [custom] | Gender | Card Thickness [Min] | Card Thickness [Min] | Card Thickness [Max] | Card Thickness [Max] | Flange Feature [diameter] | Flange Feature | Flange Feature [diameter] | Pitch [x] | Pitch [x] | Termination Rows | Mounting Type | Card Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Gold | Single | Black | Solder | 61 | 125 °C | -40 °C | 10 Áin | 0.25 Ám | Copper Alloy | 1 | Polyphenylene Sulfide (PPS) | Cantilever | 61 | Female | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 2.95 mm | Floating Bobbin Top Mount Opening | 0.116 in | 2.54 mm | 0.1 in | 1 | Through Hole | Non Specified - Single Edge |
 EDAC Inc. | Gold | Single | Black | Wire Wrap | 61 | 125 °C | -40 °C | 10 Áin | 0.25 Ám | Copper Alloy | 1 | Polyphenylene Sulfide (PPS) | Cantilever | 61 | Female | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 3.96 mm | Flush Mount Top Opening Unthreaded | 0.156 in | 2.54 mm | 0.1 in | 1 | Through Hole | Non Specified - Single Edge |
 EDAC Inc. | Gold | Single | Black | Solder | 61 | 125 °C | -40 °C | 10 Áin | 0.25 Ám | Copper Alloy | 1 | Polyphenylene Sulfide (PPS) | Cantilever | 61 | Female | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 2.95 mm | Floating Bobbin Top Mount Opening | 0.116 in | 2.54 mm | 0.1 in | 1 | Through Hole | Non Specified - Single Edge |
 EDAC Inc. | Gold | Single | Black | Solder | 61 | 125 °C | -40 °C | 10 Áin | 0.25 Ám | Copper Alloy | 1 | Polyphenylene Sulfide (PPS) | Cantilever | 61 | Female | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 4-40 Threaded Insert Top Mount Opening | 2.54 mm | 0.1 in | 1 | Through Hole Right Angle | Non Specified - Single Edge | ||
 EDAC Inc. | Gold | Single | Black | Solder | 61 | 125 °C | -40 °C | 10 Áin | 0.25 Ám | Copper Alloy | 1 | Polyphenylene Sulfide (PPS) | Cantilever | 61 | Female | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | M3 Threaded Insert Top Mount Opening | 2.54 mm | 0.1 in | 1 | Through Hole | Non Specified - Single Edge | ||
 EDAC Inc. | Gold | Single | Black | Solder | 61 | 125 °C | -40 °C | 10 Áin | 0.25 Ám | Copper Alloy | 1 | Polyphenylene Sulfide (PPS) | Cantilever | 61 | Female | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 2.95 mm | Floating Bobbin Flush Mount | 0.116 in | 2.54 mm | 0.1 in | 1 | Through Hole | Non Specified - Single Edge |
 EDAC Inc. | Gold | Single | Black | Solder | 61 | 125 °C | -40 °C | 10 Áin | 0.25 Ám | Copper Alloy | 1 | Polyphenylene Sulfide (PPS) | Cantilever | 61 | Female | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 3.25 mm | Flush Mount Side Opening Unthreaded | 0.128 " | 2.54 mm | 0.1 in | 1 | Through Hole | Non Specified - Single Edge |
 EDAC Inc. | Gold | Single | Black | Wire Wrap | 61 | 125 °C | -40 °C | 10 Áin | 0.25 Ám | Copper Alloy | 1 | Polyphenylene Sulfide (PPS) | Cantilever | 61 | Female | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 2.95 mm | Floating Bobbin Flush Mount | 0.116 in | 2.54 mm | 0.1 in | 1 | Through Hole | Non Specified - Single Edge |
 EDAC Inc. | Gold | Single | Black | Solder | 61 | 125 °C | -40 °C | 10 Áin | 0.25 Ám | Copper Alloy | 1 | Polyphenylene Sulfide (PPS) | Cantilever | 61 | Female | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 4-40 Threaded Insert Top Mount Opening | 2.54 mm | 0.1 in | 1 | Through Hole | Non Specified - Single Edge | ||
 EDAC Inc. | Gold | Single | Black | Solder | 61 | 125 °C | -40 °C | 10 Áin | 0.25 Ám | Copper Alloy | 1 | Polyphenylene Sulfide (PPS) | Cantilever | 61 | Female | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 3.96 mm | Top Mount Opening Unthreaded | 0.156 in | 2.54 mm | 0.1 in | 1 | Through Hole Right Angle | Non Specified - Single Edge |
