ALF80C Series

Manufacturer: KEMET

Catalog

CAP ALUM 9100UF 20% 63V PRESS

Part	Package / Case	Mounting Type	Polarization	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Capacitance	Tolerance	Lifetime @ Temp.	Applications	Size / Dimension [diameter]	Size / Dimension [diameter]	Impedance	Lead Spacing	Lead Spacing	ESR (Equivalent Series Resistance)	Operating Temperature [Min]	Operating Temperature [Max]	Voltage - Rated	Ripple Current @ Low Frequency	Ripple Current @ High Frequency	Height - Seated (Max)	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]
KEMET ALF80C912DD063	Radial Can - Press-Fit - 4 Lead	Press-Fit Through Hole	Polar	42 mm	1.654 in	9100 µF	20 %	8000 Hrs	General Purpose	1.378 "	35 mm	34 mOhms	0.886 in	22.5 mm	44.15 mOhm	-40 C	105 ░C	63 V	6.68 A	8.96 A
KEMET ALF80C751EH450	Radial Can - Press-Fit - 4 Lead	Press-Fit Through Hole	Polar			750 µF	20 %	9000 Hrs	General Purpose	1.575 in	40 mm	106 mOhms	0.886 in	22.5 mm	180.8 mOhm	-40 C	105 ░C	450 V	3.86 A	9.23 A	62 mm	2.441 in
KEMET ALF80C823EH025	Radial Can - Press-Fit - 4 Lead	Press-Fit Through Hole	Polar			82000 µF	20 %	9000 Hrs	General Purpose	1.575 in	40 mm	18 mOhms	0.886 in	22.5 mm	20.15 mOhm	-40 C	105 ░C	25 VDC	11.85 A	13.05 A	62 mm	2.441 in
KEMET ALF80C122DD200	Radial Can - Press-Fit - 4 Lead	Press-Fit Through Hole	Polar	42 mm	1.654 in	1.2 mF	20 %	8000 Hrs	General Purpose	1.378 "	35 mm	111 mOhms	0.886 in	22.5 mm	181.8 mOhm	-40 C	105 ░C	200 VDC	3.27 A	6.61 A
KEMET ALF80C272EL250	Radial Can - Press-Fit - 5 Lead	Press-Fit Through Hole	Polar			2700 µF	20 %	9000 Hrs	General Purpose	1.575 in	40 mm	45 mOhms	0.886 in	22.5 mm	72.08 mOhm	-40 C	105 ░C	250 V	6.42 A	11.5 A			3.228 in	82 mm
KEMET ALF80C123DF063	Radial Can - Press-Fit - 4 Lead	Press-Fit Through Hole	Polar			12000 µF	20 %	8000 Hrs	General Purpose	1.378 "	35 mm	26 mOhms	0.886 in	22.5 mm	33.9 mOhm	-40 C	105 ░C	63 V	7.99 A	10.62 A		2.047 in	52 mm
KEMET ALF80C132EL400	Radial Can - Press-Fit - 5 Lead	Press-Fit Through Hole	Polar			1300 µF	20 %	9000 Hrs	General Purpose	1.575 in	40 mm	54 mOhms	0.886 in	22.5 mm	100.6 mOhm	-40 C	105 ░C	400 V	5.07 A	11.34 A			3.228 in	82 mm
KEMET ALF80C241DC450	Radial Can - Press-Fit - 4 Lead	Press-Fit Through Hole	Polar		1.457 in	240 µF	20 %	8000 Hrs	General Purpose	1.378 "	35 mm	311 mOhms	0.886 in	22.5 mm	541.2 mOhm	-40 C	105 ░C	450 V	1.81 A	5.09 A	37 mm
KEMET ALF80C112EH350	Radial Can - Press-Fit - 4 Lead	Press-Fit Through Hole	Polar			1100 µF	20 %	9000 Hrs	General Purpose	1.575 in	40 mm	71 mOhms	0.886 in	22.5 mm	131.8 mOhm	-40 C	105 ░C	350 V	4.26 A	9.52 A	62 mm	2.441 in
KEMET ALF80C102DF250	Radial Can - Press-Fit - 4 Lead	Press-Fit Through Hole	Polar			1000 µF	20 %	8000 Hrs	General Purpose	1.378 "	35 mm	106 mOhms	0.886 in	22.5 mm	178.2 mOhm	-40 C	105 ░C	250 V	3.46 A	7.52 A		2.047 in	52 mm
