5100FE Series
Manufacturer: Belden Inc.
Beta
⌘K
CABLE 2CON 14AWG GRAY SHLD
| Part | Shield Material | Shield Coverage | Jacket (Insulation) Material | Cable Type | Number of Conductors | Conductor Material | Features | Jacket (Insulation) Thickness | Jacket (Insulation) Thickness | Wire Gauge | Length | Length | Shield Type | Conductor Insulation | Voltage | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] | Ratings | Usage | Jacket Color |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Belden Inc. | Aluminum | 100 % | Poly-Vinyl Chloride (PVC) Riser | Multi-Conductor | 2 | Copper Tinned | Drain Wire Rip Cord | 0.017 " | 0.432 mm | 14.5 AWG | 304.8 m | 1000 ft | Foil | Polypropylene (PP) | 300 VDC | 5.94 mm | 0.234 in | UL Style CMR | Security Sound | Gray |
Belden Inc. | Aluminum | 100 % | Poly-Vinyl Chloride (PVC) Riser | Multi-Conductor | 2 | Copper Tinned | Drain Wire Rip Cord | 0.017 " | 0.432 mm | 14.5 AWG | 304.8 m | 1000 ft | Foil | Polypropylene (PP) | 300 VDC | 5.94 mm | 0.234 in | UL Style CMR | Security Sound | Gray |
Belden Inc. | Aluminum | 100 % | Poly-Vinyl Chloride (PVC) Riser | Multi-Conductor | 2 | Copper Tinned | Drain Wire Rip Cord | 0.017 " | 0.432 mm | 14.5 AWG | 152.4 m | 500 ft | Foil | Polypropylene (PP) | 300 VDC | 5.94 mm | 0.234 in | UL Style CMR | Security Sound | Gray |
