ATS-04A Series

Manufacturer: Advanced Thermal Solutions Inc.

Catalog

Catalog

HEATSINK 50X50X12.7MM XCUT

...

Part	Length [x]	Length [x]	Width [x]	Width [x]	Shape	Fin Height	Fin Height	Material Finish	Type	Attachment Method	Material	Package Cooled	Thermal Resistance @ Forced Air Flow	Width	Width	Length	Fin Height [custom]	Fin Height [custom]	Fin Height [z]	Fin Height [z]	Width [y]	Width [y]	Shape [custom]	Shape [custom]	Length	Length
Advanced Thermal Solutions Inc. ATS-04A-12-C1-R0	50 mm	1.969 in	50 mm	1.969 in	Fins Square	0.5 "	12.7 mm	Blue Anodized	Top Mount	Push Pin	Aluminum	ASIC BGA CPU LGA	15.84 °C/W
Advanced Thermal Solutions Inc. ATS-04A-198-C2-R0	45 mm	1.772 in			Fins Square	0.472 in	12 mm	Blue Anodized	Top Mount	Push Pin	Aluminum	ASIC BGA CPU LGA	9.06 °C/W	1.772 in	45 mm
Advanced Thermal Solutions Inc. ATS-04A-140-C2-R0		0.984 in	25 mm	0.984 "	Fins Square	0.984 in	25 mm	Blue Anodized	Top Mount	Push Pin	Aluminum	ASIC BGA CPU LGA	7.28 °C/W			25 mm
Advanced Thermal Solutions Inc. ATS-04A-159-C2-R0	45 mm	1.772 in			Fins Square			Blue Anodized	Top Mount	Push Pin	Aluminum	ASIC BGA CPU LGA		1.772 in	45 mm		0.394 "	10 mm
Advanced Thermal Solutions Inc. ATS-04A-163-C1-R0	45 mm	1.772 in			Fins Square			Blue Anodized	Top Mount	Push Pin	Aluminum	ASIC BGA CPU LGA	2.88 °C/W	1.772 in	45 mm				1.181 in	30 mm
Advanced Thermal Solutions Inc. ATS-04A-42-C1-R0								Blue Anodized	Top Mount	Push Pin	Aluminum	ASIC BGA CPU LGA	7.3 °C/W			2.28 in			0.9 in	22.86 mm	2.4 "	60.96 mm	Rectangular	Fins	57.9 mm
Advanced Thermal Solutions Inc. ATS-04A-100-C1-R0	45 mm	1.772 in			Fins Square	0.984 in	25 mm	Blue Anodized	Top Mount	Push Pin	Aluminum	ASIC BGA CPU LGA	8.69 °C/W	1.772 in	45 mm
Advanced Thermal Solutions Inc. ATS-04A-109-C2-R1			54 mm	2.126 in	Fins Square	0.374 in	9.5 mm	Blue Anodized	Top Mount	Push Pin	Aluminum	ASIC BGA CPU LGA	27.7 °C/W			54 mm										2.126 in
Advanced Thermal Solutions Inc. ATS-04A-145-C2-R0			30 mm	1.181 in	Fins Square			Blue Anodized	Top Mount	Push Pin	Aluminum	ASIC BGA CPU LGA	4.72 °C/W			0.03 m			1.181 in	30 mm						1.181 in
Advanced Thermal Solutions Inc. ATS-04A-142-C1-R0			30 mm	1.181 in	Fins Square			Blue Anodized	Top Mount	Push Pin	Aluminum	ASIC BGA CPU LGA	10.02 °C/W			0.03 m			0.59 in	15 mm						1.181 in
