29644 Series
Manufacturer: Phoenix Contact
Beta
⌘K
RELAY GEN PURPOSE SPDT 5MA 120V
| Part | Contact Rating (Current) | Coil Resistance | Contact Form | Termination Style | Coil Type | Coil Current | Release Time | Coil Voltage | Features | Switching Voltage [Max] | Operate Time | Mounting Type | Relay Type | Contact Material | Operating Temperature [Min] | Operating Temperature [Max] | Approval Agency | Load - Max Switching | Switching Voltage |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Phoenix Contact | 5 mA 200 mA | 24 kOhms | SPDT (1 Form C) | Screw Terminal | Non Latching | 5 mA | 11 ms | 120VAC/DC | Lighted Indicator | 125 VAC 150 VDC | 7 ms | DIN Rail | General Purpose | Gold (Au) Silver Palladium (AgPd) | -20 ░C | 40 °C | |||
 Phoenix Contact | 6 A | 24 kOhms | SPST-NO (1 Form A) | Screw Terminal | Non Latching | 5 mA | 11 ms | 120VAC/DC | Lighted Indicator Socket Included Varistor | 7 ms | DIN Rail | General Purpose | Silver Nickel (AgNi) | -20 ░C | 40 °C | cULus EAC UL | 140 W 1500 VA | 250 VAC 250 VDC | |
 Phoenix Contact | 0.5 A | 24 kOhms | SPST-NO (1 Form A) | Screw Terminal | Non Latching | 5 mA | 11 ms | 120VAC/DC | Socket Included Varistor | 30 VAC 36 VDC | 7 ms | DIN Rail | General Purpose | Gold (Au) Silver Palladium (AgPd) | -20 ░C | 40 °C | |||
 Phoenix Contact | 6 A | 24 kOhms | SPDT (1 Form C) | Screw Terminal | Non Latching | 5 mA | 11 ms | 120VAC/DC | Lighted Indicator Socket Included Varistor | 7 ms | DIN Rail | General Purpose | Silver Nickel (AgNi) | -20 ░C | 40 °C | cULus EAC UL | 140 W 1500 VA | 250 VAC 250 VDC |
