MC35XS3400 Series

Catalog

IC PWR SWITCH N-CHAN 1:4 24PQFN

Part	Fault Protection	Rds On (Typ)	Voltage - Load [Max]	Voltage - Load [Min]	Output Type	Ratio - Input:Output	Operating Temperature [Max]	Operating Temperature [Min]	Interface	Voltage - Supply (Vcc/Vdd) [Max]	Voltage - Supply (Vcc/Vdd) [Min]	Features	Output Configuration	Mounting Type	Switch Type	Current - Output (Max) [Max]	Number of Outputs	Package / Case	Supplier Device Package
Freescale Semiconductor - NXP MC35XS3400CPNAR2	Current Limiting (Fixed) Open Load Detect Over Temperature Over Voltage	35 mOhm	20 V	6 V	N-Channel	1:4	150 °C	-40 °C	SPI	5.5 V	3 V	Internal PWM Slew Rate Controlled Watchdog Timer	High Side	Surface Mount	General Purpose	6 A	4	24-PowerQFN	24-PQFN (12x12)
Freescale Semiconductor - NXP MC35XS3400CPNA	Current Limiting (Fixed) Open Load Detect Over Temperature Over Voltage	35 mOhm	20 V	6 V	N-Channel	1:4	150 °C	-40 °C	SPI	5.5 V	3 V	Internal PWM Slew Rate Controlled Watchdog Timer	High Side	Surface Mount	General Purpose	6 A	4	24-PowerQFN	24-PQFN (12x12)
