XC6808 Series

Catalog

IC BATT CHG LI-ION 1CELL 6USP

Part	Charge Current - Max [Max]	Programmable Features	Mounting Type	Battery Chemistry [custom]	Operating Temperature [Max]	Operating Temperature [Min]	Package / Case	Battery Pack Voltage	Voltage - Supply (Max) [Max]	Current - Charging	Supplier Device Package [x]	Supplier Device Package	Supplier Device Package [y]	Number of Cells	Fault Protection
Torex Semiconductor Ltd XC6808B3D18R-G	40 mA	Current	Surface Mount	Lithium Ion/Polymer	85 C	-40 ¯C	6-XDFN Exposed Pad	4.35 V	6 V	Constant - Programmable	1.8	6-USP-B07	2	1	Over Current Over Temperature Reverse Current
Torex Semiconductor Ltd XC6808BNE28R-G	40 mA	Current	Surface Mount	Lithium Ion/Polymer	85 C	-40 ¯C	6-XDFN Exposed Pad	4.4 V	6 V	Constant - Programmable	1.8	6-USP-B07	2	1	Over Current Over Temperature Reverse Current
Torex Semiconductor Ltd XC6808A3D18R-G	40 mA	Current	Surface Mount	Lithium Ion/Polymer	85 C	-40 ¯C	6-XDFN Exposed Pad	4.35 V	6 V	Constant - Programmable	1.8	6-USP-B07	2	1	Over Current Over Temperature Reverse Current
Torex Semiconductor Ltd XC6808A4C18R-G	40 mA	Current	Surface Mount	Lithium Ion/Polymer	85 C	-40 ¯C	6-XDFN Exposed Pad	4.2 V	6 V	Constant - Programmable	1.8	6-USP-B07	2	1	Over Current Over Temperature Reverse Current
Torex Semiconductor Ltd XC6808B3C38R-G	40 mA	Current	Surface Mount	Lithium Ion/Polymer	85 C	-40 ¯C	6-XDFN Exposed Pad	4.2 V	6 V	Constant - Programmable	1.8	6-USP-B07	2	1	Over Current Over Temperature Reverse Current
Torex Semiconductor Ltd XC6808B4E28R-G	40 mA	Current	Surface Mount	Lithium Ion/Polymer	85 C	-40 ¯C	6-XDFN Exposed Pad	4.4 V	6 V	Constant - Programmable	1.8	6-USP-B07	2	1	Over Current Over Temperature Reverse Current
Torex Semiconductor Ltd XC6808B3D38R-G	40 mA	Current	Surface Mount	Lithium Ion/Polymer	85 C	-40 ¯C	6-XDFN Exposed Pad	4.35 V	6 V	Constant - Programmable	1.8	6-USP-B07	2	1	Over Current Over Temperature Reverse Current
Torex Semiconductor Ltd XC6808B3C18R-G	40 mA	Current	Surface Mount	Lithium Ion/Polymer	85 C	-40 ¯C	6-XDFN Exposed Pad	4.2 V	6 V	Constant - Programmable	1.8	6-USP-B07	2	1	Over Current Over Temperature Reverse Current
Torex Semiconductor Ltd XC6808BND48R-G	40 mA	Current	Surface Mount	Lithium Ion/Polymer	85 C	-40 ¯C	6-XDFN Exposed Pad	4.35 V	6 V	Constant - Programmable	1.8	6-USP-B07	2	1	Over Current Over Temperature Reverse Current
Torex Semiconductor Ltd XC6808BNC38R-G	40 mA	Current	Surface Mount	Lithium Ion/Polymer	85 C	-40 ¯C	6-XDFN Exposed Pad	4.2 V	6 V	Constant - Programmable	1.8	6-USP-B07	2	1	Over Current Over Temperature Reverse Current
