HSMA Series

Catalog

SINGLE COLOR LEDS AMBER AMB

Part	Millicandela Rating	Lens Size [x]	Lens Size [y]	Lens Color	Wavelength - Peak	Color	Viewing Angle	Height (Max) [z]	Wavelength - Dominant	Lens Style	Configuration	Size / Dimension [x]	Size / Dimension [y]	Package / Case	Lens Transparency	Mounting Type	Voltage - Forward (Vf) (Typ)	Current - Test	Supplier Device Package	Height (Max) [Max] [z]	Lens Size [diameter]	Package / Case	Height (Max) [z]
Broadcom Limited HSMA-C280	90 mcd	1 mm	0.5 mm	White	595 nm	Amber	130 °	0.4 mm	592 nm	Rectangle with Flat Top	Standard	1 mm	0.5 mm	0402 (1005 Metric)	Diffused	Surface Mount	1.9 V	20 mA
Broadcom Limited HSMA-C170-T0000	426 mcd	1.4 mm	1.25 mm		595 nm	Amber	155 °		592 nm	Rectangle with Flat Top	Standard	2 mm	1.25 mm	0805		Surface Mount	2 V	20 mA	2-SMD	0.9 mm
Broadcom Limited HSMA-A401-U45M1				Colorless	592 nm	Amber	120 °	2.1 mm	590 nm	Round with Flat Top	Standard	3.2 mm	2.8 mm	4-PLCC	Clear	Surface Mount	2.2 V	50 mA	4-PLCC		2.2 mm
Broadcom Limited HSMA-C191	90 mcd	1 mm	1.6 mm	White	595 nm	Amber	170 °		592 nm	Rectangle with Flat Top	Standard	1.6 mm	0.8 mm	0603	Diffused	Surface Mount	1.9 V	20 mA	Chip LED			1608 Metric	0.6 mm
