337-035 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 35POS 0.156
| Part | Termination Rows | Material - Insulation | Number of Positions/Bay/Row | Number of Positions | Operating Temperature [Min] | Operating Temperature [Max] | Pitch | Pitch | Termination | Contact Material | Contact Type | Number of Rows | Contact Finish | Card Type | Color | Read Out | Features | Gender | Card Thickness [Max] | Card Thickness [Min] | Contact Finish Thickness | Contact Finish Thickness | Flange Feature | Mounting Type | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Polyester Thermoplastic | 35 | 35 | -40 C | 105 ░C | 3.96 mm | 0.156 in | Wire Wrap | Copper Alloy | Cantilever | 1 | Gold | Non Specified - Single Edge | Green | Single | Card Guides | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | 4-40 Flush Mount Threaded Insert Top Opening | Through Hole | ||
 EDAC Inc. | 1 | Polyester Thermoplastic | 35 | 35 | -40 C | 105 ░C | 3.96 mm | 0.156 in | Wire Wrap | Copper Alloy | Cantilever | 1 | Gold | Non Specified - Single Edge | Green | Single | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Right Angle Through Hole | ||||
 EDAC Inc. | 1 | Polyester Thermoplastic | 35 | 35 | -40 C | 105 ░C | 3.96 mm | 0.156 in | Wire Wrap | Copper Alloy | Cantilever | 1 | Gold | Non Specified - Single Edge | Green | Single | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Flush Mount Side Opening Unthreaded | Through Hole | 0.128 " | 3.25 mm | |
 EDAC Inc. | 1 | Polyester Thermoplastic | 35 | 35 | -40 C | 105 ░C | 3.96 mm | 0.156 in | Solder | Copper Alloy | Cantilever | 1 | Gold | Non Specified - Single Edge | Green | Single | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Through Hole | 0.128 " | 3.25 mm | ||
 EDAC Inc. | 1 | Polyester Thermoplastic | 35 | 35 | -40 C | 105 ░C | 3.96 mm | 0.156 in | Solder Eyelet(s) | Copper Alloy | Cantilever | 1 | Gold | Non Specified - Single Edge | Green | Single | Card Guides | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | 4-40 Threaded Insert Top Mount Opening | Through Hole | ||
 EDAC Inc. | 1 | Polyester Thermoplastic | 35 | 35 | -40 C | 105 ░C | 3.96 mm | 0.156 in | Wire Wrap | Copper Alloy | Cantilever | 1 | Gold | Non Specified - Single Edge | Green | Single | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Side Mount Opening Unthreaded | Through Hole | 0.128 " | 3.25 mm | |
 EDAC Inc. | 1 | Polyester Thermoplastic | 35 | 35 | -40 C | 105 ░C | 3.96 mm | 0.156 in | Wire Wrap | Copper Alloy | Cantilever | 1 | Gold | Non Specified - Single Edge | Green | Single | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | 4-40 Flush Mount Threaded Insert Top Opening | Right Angle Through Hole | |||
 EDAC Inc. | 1 | Polyester Thermoplastic | 35 | 35 | -40 C | 105 ░C | 3.96 mm | 0.156 in | Wire Wrap | Copper Alloy | Cantilever | 1 | Gold | Non Specified - Single Edge | Green | Single | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Floating Bobbin Flush Mount | Right Angle Through Hole | 0.116 " | 2.95 mm | |
 EDAC Inc. | 1 | Polyester Thermoplastic | 35 | 35 | -40 C | 105 ░C | 3.96 mm | 0.156 in | Solder Eyelet(s) | Copper Alloy | Cantilever | 1 | Gold | Non Specified - Single Edge | Green | Single | Card Guides | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | 4-40 Threaded Insert Top Mount Opening | Through Hole | ||
 EDAC Inc. | 1 | Polyester Thermoplastic | 35 | 35 | -40 C | 105 ░C | 3.96 mm | 0.156 in | Solder | Copper Alloy | Cantilever | 1 | Gold | Non Specified - Single Edge | Green | Single | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Flush Mount Top Opening Unthreaded | Through Hole | 0.156 " | 3.96 mm |
