D37P24 Series
Manufacturer: Amphenol ICC (FCI)
Beta
⌘K
CONN D-SUB PLUG 37POS VERT SLDR
| Part | Voltage Rating | Flange Feature | Dielectric Material | Material Flammability Rating | Color | Contact Type | Connector Style | Termination | Number of Rows | Contact Finish | Contact Material | Features | Shell Size, Connector Layout | Mounting Type | Connector Type | Operating Temperature [Min] | Operating Temperature [Max] | Contact Finish Thickness | Current Rating (Amps) | Shell Material, Finish | Number of Positions | Contact Finish Thickness | Contact Finish Thickness |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Amphenol ICC (FCI) | 300 VDC | Housing/Shell (M3) | Polybutylene Terephthalate (PBT) | UL94 V-0 | Black | Signal | D-Sub | Solder | 2 | Gold | Phosphor Bronze | Board Lock Grounding Indents | 4 (DC C) | Through Hole | Male Pins Plug | -55 °C | 125 °C | Flash | 5 A | Steel Tin-Nickel Plated | 37 | ||
 Amphenol ICC (FCI) | 300 VDC | Housing/Shell (4-40) | Polybutylene Terephthalate (PBT) | UL94 V-0 | Black | Signal | D-Sub | Solder | 2 | Gold | Phosphor Bronze | Board Lock Grounding Indents | 4 (DC C) | Through Hole | Male Pins Plug | -55 °C | 125 °C | Flash | 5 A | Steel Tin-Nickel Plated | 37 | ||
Amphenol ICC (FCI) | 300 VDC | Housing/Shell (Unthreaded) | Polybutylene Terephthalate (PBT) | UL94 V-0 | Black | Signal | D-Sub | Solder | 2 | Gold | Phosphor Bronze | Grounding Indents | 4 (DC C) | Through Hole | Male Pins Plug | -55 °C | 125 °C | 5 A | Steel Tin-Nickel Plated | 37 | 0.76 Ám | 30 Áin | |
 Amphenol ICC (FCI) | 300 VDC | Housing/Shell (4-40) | Polybutylene Terephthalate (PBT) | UL94 V-0 | Black | Signal | D-Sub | Solder | 2 | Gold | Phosphor Bronze | Board Lock Grounding Indents | 4 (DC C) | Through Hole | Male Pins Plug | -55 °C | 125 °C | Flash | 5 A | Steel Tin-Nickel Plated | 37 | ||
Amphenol ICC (FCI) | 300 VDC | Female Screwlock (4-40) Mating Side | Polybutylene Terephthalate (PBT) | UL94 V-0 | Black | Signal | D-Sub | Solder | 2 | Gold | Phosphor Bronze | Grounding Indents | 4 (DC C) | Through Hole | Male Pins Plug | -55 °C | 125 °C | 5 A | 37 | 0.76 Ám | 30 Áin | ||
Amphenol ICC (FCI) | 300 VDC | Housing/Shell (4-40) | Polybutylene Terephthalate (PBT) | UL94 V-0 | Black | Signal | D-Sub | Solder | 2 | Gold | Phosphor Bronze | Grounding Indents | 4 (DC C) | Through Hole | Male Pins Plug | -55 °C | 125 °C | Flash | 5 A | 37 | |||
Amphenol ICC (FCI) | 300 VDC | Housing/Shell (M3) | Polybutylene Terephthalate (PBT) | UL94 V-0 | Black | Signal | D-Sub | Solder | 2 | Gold | Phosphor Bronze | Board Lock Grounding Indents | 4 (DC C) | Through Hole | Male Pins Plug | -55 °C | 125 °C | Flash | 5 A | 37 | |||
Amphenol ICC (FCI) | 300 VDC | Female Screwlock (4-40) Mating Side | Polybutylene Terephthalate (PBT) | UL94 V-0 | Black | Signal | D-Sub | Solder | 2 | Gold | Phosphor Bronze | Grounding Indents | 4 (DC C) | Through Hole | Male Pins Plug | -55 °C | 125 °C | 5 A | 37 | 0.76 Ám | 30 Áin | ||
Amphenol ICC (FCI) | 300 VDC | Female Screwlock (M3) Mating Side | Polybutylene Terephthalate (PBT) | UL94 V-0 | Black | Signal | D-Sub | Solder | 2 | Gold | Brass | Board Lock Grounding Indents | 4 (DC C) | Through Hole | Male Pins Plug | -55 °C | 125 °C | 5 A | Steel Tin-Nickel Plated | 37 | 0.76 Ám | 30 Áin | |
Amphenol ICC (FCI) | 300 VDC | Housing/Shell (4-40) | Polybutylene Terephthalate (PBT) | UL94 V-0 | Black | Signal | D-Sub | Solder | 2 | Gold | Phosphor Bronze | Grounding Indents | 4 (DC C) | Through Hole | Male Pins Plug | -55 °C | 125 °C | 5 A | 37 | 0.76 Ám | 30 Áin |
