2823401 Series

Manufacturer: TE Connectivity Raychem Cable Protection

Catalog

10P,2MM,PL HDR,SRVT,2.8,0.38AU,T

Part	Shrouding	Pitch - Mating [x]	Pitch - Mating [x]	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Contact Material	Contact Finish - Mating	Insulation Material	Insulation Height [custom]	Insulation Height [custom]	Style	Material Flammability Rating	Contact Shape	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Mounting Type	Number of Rows	Insulation Color	Connector Type	Voltage Rating	Number of Positions	Number of Positions Loaded	Contact Length - Post [x]	Contact Length - Post [x]	Fastening Type	Operating Temperature [Max]	Operating Temperature [Min]	Contact Length - Mating	Contact Length - Mating	Termination	Current Rating (Amps)	Contact Type	Contact Finish - Post	Number of Positions
TE Connectivity Raychem Cable Protection 1-2823401-0	Shrouded - 2 Wall	0.079 in	2 mm	15 µin	0.38 µm	Phosphor Bronze	Gold	Thermoplastic	5.51 mm	0.217 in	Board to Board Cable	UL94 V-0	Square	157.5 Áin	4 Ám	Through Hole	1	Black	Header	125 VAC	10	All	0.11 in	2.8 mm	Push-Pull	125 °C	-40 °C	4 mm	0.157 in	Solder	2 A	Male Pin	Tin
TE Connectivity Raychem Cable Protection 1-2823401-6	Shrouded - 2 Wall	0.079 in	2 mm	15 µin	0.38 µm	Phosphor Bronze	Gold	Thermoplastic	5.51 mm	0.217 in	Board to Board Cable	UL94 V-0	Square	157.5 Áin	4 Ám	Through Hole	1	Black	Header	125 VAC		All	0.11 in	2.8 mm	Push-Pull	125 °C	-40 °C	4 mm	0.157 in	Solder	2 A	Male Pin	Tin	16
TE Connectivity Raychem Cable Protection 2823401-3	Shrouded - 2 Wall	0.079 in	2 mm	15 µin	0.38 µm	Phosphor Bronze	Gold	Thermoplastic	5.51 mm	0.217 in	Board to Board Cable	UL94 V-0	Square	157.5 Áin	4 Ám	Through Hole	1	Black	Header	125 VAC		All	0.11 in	2.8 mm	Push-Pull	125 °C	-40 °C	4 mm	0.157 in	Solder	2 A	Male Pin	Tin
TE Connectivity Raychem Cable Protection 2823401-5	Shrouded - 2 Wall	0.079 in	2 mm	15 µin	0.38 µm	Phosphor Bronze	Gold	Thermoplastic	5.51 mm	0.217 in	Board to Board Cable	UL94 V-0	Square	157.5 Áin	4 Ám	Through Hole	1	Black	Header	125 VAC		All	0.11 in	2.8 mm	Push-Pull	125 °C	-40 °C	4 mm	0.157 in	Solder	2 A	Male Pin	Tin
TE Connectivity Raychem Cable Protection 1-2823401-4	Shrouded - 2 Wall	0.079 in	2 mm	15 µin	0.38 µm	Phosphor Bronze	Gold	Thermoplastic	5.51 mm	0.217 in	Board to Board Cable	UL94 V-0	Square	157.5 Áin	4 Ám	Through Hole	1	Black	Header	125 VAC	14	All	0.11 in	2.8 mm	Push-Pull	125 °C	-40 °C	4 mm	0.157 in	Solder	2 A	Male Pin	Tin
TE Connectivity Raychem Cable Protection 2823401-4	Shrouded - 2 Wall	0.079 in	2 mm	15 µin	0.38 µm	Phosphor Bronze	Gold	Thermoplastic	5.51 mm	0.217 in	Board to Board Cable	UL94 V-0	Square	157.5 Áin	4 Ám	Through Hole	1	Black	Header	125 VAC	4	All	0.11 in	2.8 mm	Push-Pull	125 °C	-40 °C	4 mm	0.157 in	Solder	2 A	Male Pin	Tin
TE Connectivity Raychem Cable Protection 2823401-8	Shrouded - 2 Wall	0.079 in	2 mm	15 µin	0.38 µm	Phosphor Bronze	Gold	Thermoplastic	5.51 mm	0.217 in	Board to Board Cable	UL94 V-0	Square	157.5 Áin	4 Ám	Through Hole	1	Black	Header	125 VAC	8	All	0.11 in	2.8 mm	Push-Pull	125 °C	-40 °C	4 mm	0.157 in	Solder	2 A	Male Pin	Tin
TE Connectivity Raychem Cable Protection 1-2823401-5	Shrouded - 2 Wall	0.079 in	2 mm	15 µin	0.38 µm	Phosphor Bronze	Gold	Thermoplastic	5.51 mm	0.217 in	Board to Board Cable	UL94 V-0	Square	157.5 Áin	4 Ám	Through Hole	1	Black	Header	125 VAC	15	All	0.11 in	2.8 mm	Push-Pull	125 °C	-40 °C	4 mm	0.157 in	Solder	2 A	Male Pin	Tin
TE Connectivity Raychem Cable Protection 1-2823401-2	Shrouded - 2 Wall	0.079 in	2 mm	15 µin	0.38 µm	Phosphor Bronze	Gold	Thermoplastic	5.51 mm	0.217 in	Board to Board Cable	UL94 V-0	Square	157.5 Áin	4 Ám	Through Hole	1	Black	Header	125 VAC	12	All	0.11 in	2.8 mm	Push-Pull	125 °C	-40 °C	4 mm	0.157 in	Solder	2 A	Male Pin	Tin
TE Connectivity Raychem Cable Protection 2823401-9	Shrouded - 2 Wall	0.079 in	2 mm	15 µin	0.38 µm	Phosphor Bronze	Gold	Thermoplastic	5.51 mm	0.217 in	Board to Board Cable	UL94 V-0	Square	157.5 Áin	4 Ám	Through Hole	1	Black	Header	125 VAC	9	All	0.11 in	2.8 mm	Push-Pull	125 °C	-40 °C	4 mm	0.157 in	Solder	2 A	Male Pin	Tin
