2N6565 Series

Sens SCR 400V 0.8A 200µA TO92

Manufacturer: Littelfuse/Commercial Vehicle Products

Catalog

Sens SCR 400V 0.8A 200µA TO92

Part	Current - Gate Trigger (Igt) (Max) [Max]	Operating Temperature [Min]	Operating Temperature [Max]	Current - Off State (Max) [Max]	Current - Hold (Ih) (Max) [Max]	Voltage - Gate Trigger (Vgt) (Max) [Max]	Mounting Type	Current - On State (It (AV)) (Max)	Supplier Device Package	Voltage - Off State	SCR Type	Voltage - On State (Vtm) (Max) [Max]	Current - Non Rep. Surge 50, 60Hz (Itsm)	Current - On State (It (RMS)) (Max) [Max]	Package / Case
Littelfuse/Commercial Vehicle Products 2N6565RP	200 µA	-40 °C	110 °C	1 µA	5 mA	800 mV	Through Hole	510 mA	TO-92-3	400 V	Sensitive Gate	1.7 V	16 A 20 A	800 mA	TO-226-3 TO-92-3
Littelfuse/Commercial Vehicle Products 2N6565	200 µA	-40 °C	110 °C	1 µA	5 mA	800 mV	Through Hole	510 mA	TO-92	400 V	Sensitive Gate	1.7 V	16 A 20 A	800 mA	TO-226-3 TO-92-3

Catalog

Sens SCR 400V 0.8A 200µA TO92

Key Features

• RoHS compliant

• Glass-passivated junctions

• Voltage capability up to 600 V

• Surge capablity up to 20 A

Description

Excellent unidirectional switches for phase control applications such as heating and motor speed controls. Sensitive gate SCRs are easily triggered with microAmps of current as furnished by sense coils, proximity switches, and microprocessors.
