1609037 Series
Manufacturer: TE Connectivity Raychem Cable Protection
Beta
⌘K
LINE FILTER 250VAC 6A CHASSIS
| Part | Applications | Termination Style | Current | Inductance | Voltage - Rated AC | Filter Type | Frequency - Operating [Max] | Frequency - Operating [Min] | Approval Agency | Mounting Type | Operating Temperature [Min] | Operating Temperature [Max] | Configuration |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity Raychem Cable Protection | General Purpose | Quick Connect | 6 A | 5.1 mH | 250 V | Single Phase | 60 Hz | 50 Hz | CSA UR VDE | Chassis Mount | -10 °C | 40 °C | Single Stage |
 TE Connectivity Raychem Cable Protection | General Purpose | Quick Connect | 20 A | 4.55 mH | 250 V | Single Phase | 60 Hz | 50 Hz | CSA UR VDE | Chassis Mount | -10 °C | 40 °C | Single Stage |
 TE Connectivity Raychem Cable Protection | General Purpose | Threaded Post (8-32) | 30 A | 900 µH | 250 V | Single Phase | 60 Hz | 50 Hz | CSA UR VDE | Chassis Mount | -10 °C | 40 °C | Single Stage |
 TE Connectivity Raychem Cable Protection | General Purpose | Quick Connect | 20 A | 6 mH | 250 V | Single Phase | 60 Hz | 50 Hz | CSA UR VDE | Chassis Mount | -10 °C | 40 °C | Two Stage |
 TE Connectivity Raychem Cable Protection | General Purpose | Quick Connect | 20 A | 2.88 mH | 250 V | Single Phase | 60 Hz | 50 Hz | UR VDE | Chassis Mount | -10 °C | 40 °C | Two Stage |
 TE Connectivity Raychem Cable Protection | General Purpose | Quick Connect | 20 A | 440 µH | 250 V | Single Phase | 60 Hz | 50 Hz | UL VDE | Chassis Mount | -10 °C | 40 °C | Single Stage |
 TE Connectivity Raychem Cable Protection | General Purpose | Quick Connect | 10 A | 4.97 mH | 250 V | Single Phase | 60 Hz | 50 Hz | CSA UR VDE | Chassis Mount | -10 °C | 40 °C | Single Stage |
 TE Connectivity Raychem Cable Protection | General Purpose | Quick Connect | 4 A | 7 mH | 250 V | Single Phase | 60 Hz | 50 Hz | CSA UR VDE | Chassis Mount | -10 °C | 40 °C | Single Stage |
