2041061 Series
Manufacturer: TE Connectivity Raychem Cable Protection
Beta
⌘K
CONN HEADER SMD 7POS 2MM
| Part | Insulation Material | Number of Positions Loaded | Contact Finish - Mating | Pitch - Mating [x] | Pitch - Mating [x] | Material Flammability Rating | Applications | Contact Finish Thickness - Mating | Number of Positions | Voltage Rating | Termination | Contact Material | Contact Type | Insulation Color | Operating Temperature [Max] | Operating Temperature [Min] | Current Rating (Amps) | Contact Length - Mating | Contact Length - Mating | Contact Shape | Features | Connector Type | Number of Rows | Fastening Type | Shrouding | Style | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity Raychem Cable Protection | Nylon 9T Polyamide (PA9T) | All | Gold | 0.079 in | 2 mm | UL94 V-0 | Automotive General Purpose Industrial Medical | Flash | 7 | 250 VAC | Solder | Phosphor Bronze | Male Pin | Natural | 105 ░C | -55 °C | 3 A | 0.138 in | 3.5 mm | Square | Pick and Place Solder Retention | Header | 1 | Locking Ramp | Shrouded - 4 Wall | Board to Cable/Wire | Surface Mount |
