SM2A31 Series
Manufacturer: BANNER ENGINEERING
Beta
⌘K
MINI-BEAM: RECEIVERRANGE: 3
| Part | Ingress Protection | Adjustment Type | Sensing Distance | Sensing Distance | Sensing Method | Response Time | Light Source | Connection Method | Operating Temperature [Min] | Operating Temperature [Max] | Voltage - Supply [Min] | Voltage - Supply [Max] | Output Configuration |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 BANNER ENGINEERING | 12 13 2 3 3S 4 4X 6 IEC IEC IP67 IP67 NEMA 1 NEMA 12 NEMA 13 NEMA 2 NEMA 3 NEMA 3S NEMA 4 NEMA 4X NEMA 6 | Adjustable Potentiometer | 30 cm | 11.811 " | Through-Beam | 2 ms | Infrared (880nm) | Connector | -20 ░C | 70 °C | 24 VAC | 240 VAC | |
BANNER ENGINEERING | 12 13 2 3 3S 4 4X 6 IEC IEC IP67 IP67 NEMA 1 NEMA 12 NEMA 13 NEMA 2 NEMA 3 NEMA 3S NEMA 4 NEMA 4X NEMA 6 | Adjustable Potentiometer | 30 cm | 11.811 " | Through-Beam | 2 ms | RED (650nm) | Connector | -20 ░C | 70 °C | 24 VAC | 240 VAC | SPST - Dark-ON/Light-ON |
