PTVS3 Series

Catalog

TVS DIODE 76VWM 130VC AXIAL

Part	Voltage - Reverse Standoff (Typ)	Applications	Bidirectional Channels [custom]	Package / Case	Package / Case [custom]	Supplier Device Package	Mounting Type	Type	Current - Peak Pulse (10/1000µs)	Current - Peak Pulse (10/1000µs) [Max]	Current - Peak Pulse (10/1000µs)	Current - Peak Pulse (10/1000µs) [Min]	Voltage - Breakdown (Min) [Min]	Capacitance @ Frequency	Operating Temperature [Max]	Operating Temperature [Min]	Voltage - Clamping (Max) @ Ipp [Max]
Bourns Inc. PTVS3-076C	76 V	General Purpose	1	Axial Right Angle Bend	24.15 mm	Axial	Through Hole	Zener	3000 A	20 µs	3 kA	8 µs	85 V	1700 pF	150 °C	-55 °C	140 V
Bourns Inc. PTVS3-058C	58 V	General Purpose	1	Axial Right Angle Bend	24.15 mm	Axial	Through Hole	Zener	3000 A	20 µs	3 kA	8 µs	64 V	10 kHz 2300 pF	150 °C	-55 °C	110 V
Bourns Inc. PTVS3-076C-M	76 V	General Purpose	1	2-SMD Flat Leads		2-SMD	Surface Mount	Zener	3000 A	20 µs	3 kA	8 µs	85 V	1700 pF	125 °C	-55 ░C	135 V
Bourns Inc. PTVS3-058C-SH	58 V	General Purpose	1	2-SMD		2-SMD	Surface Mount	Zener	3000 A	20 µs	3 kA	8 µs	64 V	10 kHz 2300 pF	125 °C	-55 ░C	110 V
