RR9KI1500 Series
Manufacturer: GlobTek, Inc.
Beta
⌘K
AC/DC DSKTP/WALL MT ADPT 24V 36W
| Part | Applications | Cord Length | Cord Length | Operating Temperature [Min] | Operating Temperature [Max] | Region Utilized | Output Connector [diameter] | Output Connector | Output Connector [x] | Voltage - Output | Approval Agency | Polarization | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [x] | Current - Output (Max) [Max] | Power (Watts) | Standard Number | Input Connector | Form | Input Type | Voltage - Input [Max] | Voltage - Input [Min] | Efficiency | No Load Power Consumption |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 GlobTek, Inc. | Household Appliances ITE (Commercial) Medical | 60.2 in | 1.53 m | -20 ░C | 40 °C | International | 2.5 mm 5.5 mm | Barrel Plug | 11 mm | 24 V | CB CCC CE cETLus EAC ETL FCC LPS PSE RCM S-Mark UkrSEPRO UL VCCI | Positive Center | 1.83 " | 38.2 mm | 46.5 mm | 101.7 mm | 1.5 in | 4 in | 1.5 A | 36 W | 1310 60335-1 60601-1-11 60601-1-2 60950-1 62368-1 | IEC 320-C8 Multi-Blade | Desktop Wall Mount | Cord (Sold Separately) Multi-Blade (Single Blade Included) | 264 VAC | 90 VAC | Level VI | 75 mW |
 GlobTek, Inc. | Household Appliances ITE (Commercial) Medical | 47.2 in | 1.2 m | -20 ░C | 40 °C | International | Barrel Plug Kit (1.3mm x 3.5mm | 24 V | CB CCC CE cETLus EAC ETL FCC LPS PSE RCM S-Mark UkrSEPRO UL VCCI | 1.83 " | 38.2 mm | 46.5 mm | 101.7 mm | 1.5 in | 4 in | 1.5 A | 36 W | 1310 60335-1 60601-1-11 60601-1-2 60950-1 62368-1 | IEC 320-C8 Multi-Blade | Desktop Wall Mount | Cord (Sold Separately) Multi-Blade (Single Blade Included) | 264 VAC | 90 VAC | Level VI | 75 mW |
