0603HP Series

Manufacturer: Delta Electronics/Components

Catalog

FIXED IND 2.2NH 900MA 180MOHM SM

Part	Frequency - Self Resonant	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Shielding	Operating Temperature [Min]	Operating Temperature [Max]	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Mounting Type	Package / Case	Package / Case	DC Resistance (DCR)	Type	Current Rating (Amps)	Material - Core	Q @ Freq [custom]	Q @ Freq [custom]	Inductance Frequency - Test	Tolerance	Inductance	Q @ Freq	Q @ Freq [custom]	Q @ Freq [custom]
Delta Electronics/Components 0603HP-2N2EKTS	15 GHz	1.4 mm	1.15 mm	0.055 "	0.045 "	Unshielded	-55 C	125 °C	0.6 mm	0.024 in	Surface Mount	1608 Metric	0603	180 mOhm	Drum Core Wirewound	900 mA	Ceramic	13	250 MHz	250 MHz	10 %
Delta Electronics/Components 0603HP-230EGTS	3 GHz	1.4 mm	1.15 mm	0.055 "	0.045 "	Unshielded	-55 C	125 °C	0.6 mm	0.024 in	Surface Mount	1608 Metric	0603	180 mOhm	Drum Core Wirewound	0.85 A	Ceramic			250 MHz	2 %	23 nH	40 250 MHz
Delta Electronics/Components 0603HP-6N8EGTS	5.8 GHz	1.4 mm	1.15 mm	0.055 "	0.045 "	Unshielded	-55 C	125 °C	0.6 mm	0.024 in	Surface Mount	1608 Metric	0603	42 mOhms	Drum Core Wirewound	1.4 A	Ceramic			250 MHz	2 %	6.8 nH	42 250 MHz
Delta Electronics/Components 0603HP-4N3ECTS	7.5 GHz	1.4 mm	1.15 mm	0.055 "	0.045 "	Unshielded	-55 C	125 °C	0.6 mm	0.024 in	Surface Mount	1608 Metric	0603	80 mOhm	Drum Core Wirewound	1.3 A	Ceramic			250 MHz	0.2 nH	4.3 nH		250 MHz	30
Delta Electronics/Components 0603HP-720EKTS	1.9 GHz	1.4 mm	1.15 mm	0.055 "	0.045 "	Unshielded	-55 C	125 °C	0.6 mm	0.024 in	Surface Mount	1608 Metric	0603	420 mOhm	Drum Core Wirewound	0.55 A	Ceramic			150 MHz	10 %	72 nH	46 250 MHz
Delta Electronics/Components 0603HP-230EKTS	3 GHz	1.4 mm	1.15 mm	0.055 "	0.045 "	Unshielded	-55 C	125 °C	0.6 mm	0.024 in	Surface Mount	1608 Metric	0603	180 mOhm	Drum Core Wirewound	0.85 A	Ceramic			250 MHz	10 %	23 nH	40 250 MHz
Delta Electronics/Components 0603HP-121EGTS	1.55 GHz	1.4 mm	1.15 mm	0.055 "	0.045 "	Unshielded	-55 C	125 °C	0.6 mm	0.024 in	Surface Mount	1608 Metric	0603	720 mOhm	Drum Core Wirewound	0.42 A	Ceramic			150 MHz	2 %	120 nH	47 250 MHz
Delta Electronics/Components 0603HP-301EJTS	990 MHz	1.4 mm	1.15 mm	0.055 "	0.045 "	Unshielded	-55 C	125 °C	0.6 mm	0.024 in	Surface Mount	1608 Metric	0603	2.8 Ohm	Drum Core Wirewound	0.22 A	Ceramic			100 MHz	5 %	300 nH	47 250 MHz
Delta Electronics/Components 0603HP-361EGTS	930 MHz	1.4 mm	1.15 mm	0.055 "	0.045 "	Unshielded	-55 C	125 °C	0.6 mm	0.024 in	Surface Mount	1608 Metric	0603	4 Ohm	Drum Core Wirewound	0.17 A	Ceramic			100 MHz	2 %	360 nH	47 250 MHz
Delta Electronics/Components 0603HP-4N3EHTS	7.5 GHz	1.4 mm	1.15 mm	0.055 "	0.045 "	Unshielded	-55 C	125 °C	0.6 mm	0.024 in	Surface Mount	1608 Metric	0603	80 mOhm	Drum Core Wirewound	1.3 A	Ceramic			250 MHz	3 %	4.3 nH		250 MHz	30
