MAX77839 Series

Manufacturer: Analog Devices Inc./Maxim Integrated

Catalog

5.5V INPUT, 4.4A/3.6A SWITCHING CURRENT 6ΜA IQBUCK-BOOST CONVERTER

Part	Voltage - Output (Max) [Max]	Operating Temperature [Min]	Operating Temperature [Max]	Frequency - Switching	Current - Output	Voltage - Input (Max) [Max]	Voltage - Output (Min/Fixed)	Output Configuration	Supplier Device Package [x]	Supplier Device Package	Supplier Device Package [y]	Topology	Number of Outputs	Mounting Type	Output Type	Function	Package / Case	Voltage - Input (Min) [Min]	Voltage - Output [Max]	Voltage - Output [Min]	Voltage - Input	Applications	Board Type	Supplied Contents	Outputs and Type	Outputs and Type	Main Purpose	Voltage - Output	Regulator Topology	Voltage - Input [Min]	Voltage - Input [Max]	Utilized IC / Part	Contents
Analog Devices Inc./Maxim Integrated MAX77839CEWL+T	5.3 V	-40 C	125 °C	2.2 MHz	3 A	5.5 V	2.3 V	Positive	2.07	15-WLP	1.51	Buck-Boost	1	Surface Mount	Adjustable	Step-Up/Step-Down	15-WFBGA WLBGA	1.8 V
Analog Devices Inc./Maxim Integrated MAX77839CEFQ+T	5.3 V	-40 C	125 °C	2.2 MHz	3 A	5.5 V	2.3 V	Positive	2.5	11-FC2QFN	2	Buck-Boost	1	Surface Mount	Adjustable	Step-Up/Step-Down	11-UFQFN	1.8 V
Analog Devices Inc./Maxim Integrated MAX77839AEFQ+		-40 C	125 °C						2.5	11-FC2QFN	2		1	Surface Mount			11-UFQFN		5.3 V	2.3 V	5.5 V	Battery Powered Devices Converter
Analog Devices Inc./Maxim Integrated MAX77839AEWL+		-40 C	125 °C						2.07	15-WLP	1.51		1	Surface Mount			15-WFBGA WLBGA		5.3 V	2.3 V	5.5 V	1-Cell Lithium Ion Converter Portable Communication Devices
Analog Devices Inc./Maxim Integrated MAX77839AEFQ+T	5.3 V	-40 C	125 °C	2.2 MHz	3 A	5.5 V	2.3 V	Positive	2.5	11-FC2QFN	2	Buck-Boost	1	Surface Mount	Adjustable	Step-Up/Step-Down	11-UFQFN	1.8 V
Analog Devices Inc./Maxim Integrated MAX77839AEWL+T		-40 C	125 °C						2.07	15-WLP	1.51		1	Surface Mount			15-WFBGA WLBGA		5.3 V	2.3 V	5.5 V	Battery Powered Devices Converter
Analog Devices Inc./Maxim Integrated MAX77839BEFQ+T	5.3 V	-40 C	125 °C	2.2 MHz	3 A	5.5 V	2.3 V	Positive	2.5	11-FC2QFN	2	Buck-Boost	1	Surface Mount	Adjustable	Step-Up/Step-Down	11-UFQFN	1.8 V
Analog Devices Inc./Maxim Integrated MAX77839BEFQ+		-40 C	125 °C						2.5	11-FC2QFN	2		1	Surface Mount			11-UFQFN		5.3 V	2.3 V	5.5 V	Battery Powered Devices Converter
Analog Devices Inc./Maxim Integrated MAX77839QEVKIT#				2.2 MHz	2.5 A																		Fully Populated	Board(s)	1	1 Non-Isolated Output Non-Isolated	DC/DC Step Up or Down	3.3 V	Buck-Boost	1.8 V	5.5 V	MAX77839	Board(s)
Analog Devices Inc./Maxim Integrated MAX77839DEWL+	5.3 V	-40 C	125 °C	2.2 MHz	3 A	5.5 V	2.3 V	Positive	2.07	15-WLP	1.51	Buck-Boost	1	Surface Mount	Adjustable	Step-Up/Step-Down	15-WFBGA WLBGA	1.8 V
