-40V Dual Pch+Pch, DFN2020, Power MOSFET
Description
AI
UT6JB5 is a DFN package MOSFET suitable for switching applications.
Beta
⌘K
-40V Dual Pch+Pch, DFN2020, Power MOSFET
-40V Dual Pch+Pch, DFN2020, Power MOSFET
| Part | Technology | Gate Charge (Qg) (Max) @ Vgs | Mounting Type | Rds On (Max) @ Id, Vgs | Configuration | Drain to Source Voltage (Vdss) | Vgs(th) (Max) @ Id | Power - Max [Max] | Supplier Device Package | Operating Temperature | Input Capacitance (Ciss) (Max) @ Vds [Max] | Package / Case | Current - Continuous Drain (Id) @ 25°C |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Rohm Semiconductor | MOSFET (Metal Oxide) | 6.2 nC | Surface Mount | 122 mOhm | 2 P-Channel (Dual) | 40 V | 2.5 V | 2 W | HUML2020L8 | 150 °C | 265 pF | 6-PowerUDFN | 3.5 A |
