Terminal Block Tools & Accessories RBO 10-VS 2
Terminal Block Tools & Accessories RBO 10-VS 2
Terminal Block Tools & Accessories RBO 10-VS 2
| Part | Wire Gauge or Range - mm² [Min] | Wire Gauge or Range - mm² [Max] | Number of Levels | Current - IEC | Housing Color | Termination Style | Type | Voltage - UL | Voltage - IEC | Mounting Type | Number of Positions | Wire Gauge or Range - AWG | Material - Insulation | Length | Length | Material Flammability Rating | Height (Max) [z] | Height (Max) [z] | Current - UL | Wire Gauge or Range - AWG [Max] | Wire Gauge or Range - AWG [Min] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Phoenix Contact | 25 mm² | 300 mm² | 1 | 520 A | Blue | Bolt and Nut | NEMA Open Construction | 1 kV | 1 kV | DIN Rail | 2 | 4 AWG 1000 MCM (kcmil) | |||||||||
Phoenix Contact | 0.1 mm² | 10 mm² | 1 | 57 A | Gray | Bolt and Nut | NEMA Open Construction | 800 V | Direct Mount | 8 | Nylon Polyamide (PA) | 53.3 mm | 2.098 in | UL94 V-0 | 37 mm | 1.457 in | 45 A | 26 AWG | 8 AWG | ||
Phoenix Contact | 0.1 mm² | 10 mm² | 1 | 57 A | Gray | Bolt and Nut | NEMA Open Construction | 800 V | Direct Mount | 4 | Nylon Polyamide (PA) | 53.3 mm | 2.098 in | UL94 V-0 | 37 mm | 1.457 in | 45 A | 26 AWG | 8 AWG | ||
Phoenix Contact | 6 mm² | 70 mm² | 1 | 192 A | Gray | Bolt and Nut | NEMA Open Construction | 1500 V | DIN Rail | 175 A | 8 AWG | 2 aught AWG | |||||||||
Phoenix Contact | 6 mm² | 70 mm² | 1 | 192 A | Black Yellow | Bolt and Nut | NEMA Open Construction | 1500 V | DIN Rail | 2 | 175 A | 8 AWG | 2 aught AWG |
