4TL1 Series
Manufacturer: Honeywell Sensing and Productivity Solutions
Beta
⌘K
SWITCH TOGGLE 4PDT 15A 125V
| Part | Ingress Protection | Illumination | Panel Cutout Dimensions [diameter] | Bushing Thread | Voltage Rating - AC | Termination Style | Circuit | Actuator Type | Actuator Length [x] | Operating Temperature [Min] | Operating Temperature [Max] | Switch Function | Mounting Type | Current Rating (Amps) | Actuator Material |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Honeywell Sensing and Productivity Solutions | Environment Sealed | Non-Illuminated | 12.4 mm | 15/32-32 | 125 V | Screw Terminal | 4PDT | Locking Lever | 22.35 mm | -65 ░C | 71 °C | On-On | Panel Mount | 15 A | |
 Honeywell Sensing and Productivity Solutions | Environment Sealed | Non-Illuminated | 12.4 mm | 15/32-32 | 125 V | Screw Terminal | 4PDT | Standard Round | 17.27 mm | -65 ░C | 71 °C | Mom-On-Mom | Panel Mount | 10 A | Nickel Plated |
Honeywell Sensing and Productivity Solutions | Environment Sealed | Non-Illuminated | 12.4 mm | 15/32-32 | 125 V | Screw Terminal | 4PDT | Locking Lever | -65 ░C | 71 °C | On-On | Panel Mount | 15 A | ||
Honeywell Sensing and Productivity Solutions | Environment Sealed | Non-Illuminated | 12.4 mm | 15/32-32 | 125 V | Screw Terminal | 4PDT | Locking Lever | 26.67 mm | -65 ░C | 71 °C | On-On-On | Panel Mount | 15 A | Nickel Plated |
Honeywell Sensing and Productivity Solutions | Environment Sealed | Non-Illuminated | 12.4 mm | 15/32-32 | 125 V | Screw Terminal | 4PDT | Standard Round | 17.27 mm | -65 ░C | 71 °C | On-On-Mom | Panel Mount | 10 A | Nickel Plated |
Honeywell Sensing and Productivity Solutions | Environment Sealed | Non-Illuminated | 12.4 mm | 15/32-32 | 125 V | Screw Terminal | 4PDT | Standard Round | 17.27 mm | -65 ░C | 71 °C | Mom-On-Mom | Panel Mount | 10 A | Nickel Plated |
 Honeywell Sensing and Productivity Solutions | Environment Sealed | Non-Illuminated | 12.4 mm | 15/32-32 | 125 V | Screw Terminal | 4PST-NO | Standard Round | 17.27 mm | -65 ░C | 71 °C | Off-Mom | Panel Mount | 10 A | Nickel Plated |
Honeywell Sensing and Productivity Solutions | Environment Sealed | Non-Illuminated | 12.4 mm | 15/32-32 | 125 V | Screw Terminal | 4PDT | Locking Lever | 26.67 mm | -65 ░C | 71 °C | On-On-On | Panel Mount | 15 A | Nickel Plated |
 Honeywell Sensing and Productivity Solutions | Environment Sealed | Non-Illuminated | 12.4 mm | 15/32-32 | 125 V | Screw Terminal | 4PDT | Locking Lever | 26.67 mm | -65 ░C | 71 °C | On-On-Mom | Panel Mount | 10 A | Nickel Plated |
Honeywell Sensing and Productivity Solutions | Environment Sealed | Non-Illuminated | 12.4 mm | 15/32-32 | 125 V | Screw Terminal | 4PDT | Locking Lever | 26.67 mm | -65 ░C | 71 °C | On-On-On | Panel Mount | 15 A | Nickel Plated |
