HFW32S Series
Manufacturer: Amphenol ICC (FCI)
Beta
⌘K
CONN FFC FPC VERT 32POS 1MM SMD
| Part | Housing Color | Mating Cycles | Cable End Type | Pitch | Pitch | Contact Material | FFC, FCB Thickness [custom] | FFC, FCB Thickness [custom] | Flat Flex Type | Voltage Rating | Connector/Contact Type | Contact Finish | Material Flammability Rating | Mounting Type | Housing Material | Height Above Board [z] | Height Above Board [z] | Operating Temperature [Min] | Operating Temperature [Max] | Termination | FFC, FCB Thickness |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Amphenol ICC (FCI) | Black | 30 | Straight Tapered | 1 mm | 0.039 in | Phosphor Bronze | 0.3 mm | 0.33 mm | FFC FPC | 100 V | Contacts Vertical - 1 Sided | Tin | UL94 V-0 | Surface Mount | Glass Filled Nylon 6T Polyamide (PA6T) | 0.209 in | 5.3 mm | -55 C | 85 °C | Solder | |
 Amphenol ICC (FCI) | Black | 30 | Straight Tapered | 1 mm | 0.039 in | Phosphor Bronze | FFC FPC | 100 V | Contacts Top | Tin | UL94 V-0 | Surface Mount | Liquid Crystal Polymer (LCP) Halogen Free | 0.209 in | 5.3 mm | -55 C | 105 ░C | Solder | 0.3 mm |
