6STR Series
Manufacturer: TE Connectivity AMP Connectors
Beta
⌘K
CONN BARRIER STRIP 6CIRC 0.375"
| Part | Number of Rows | Mounting Type | Operating Temperature | Bottom Termination | Color | Terminal Block Type | Features | Barrier Type | Wire Gauge [Max] | Wire Gauge [Min] | Terminal Screw Material | Number of Circuits | Terminal Screw Finish | Voltage Rating | Current Rating (Amps) | Number of Wire Entries | Top Termination | Pitch | Pitch | Material Flammability Rating | Material - Insulation | Number of Circuits [custom] | Number of Wire Entries [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
TE Connectivity AMP Connectors | 1 | Chassis Panel Through Hole | 105 C | Solder Turret | Black | Barrier Block | Flange | 3 Wall (Tri) | 22 AWG | 12 AWG | Steel | 6 | Clear Chromate Zinc | 300 VDC | 25 A | 6 | Screws with Captive Plate | 9.53 mm | 0.375 in | UL94 V-0 | Nylon Polyamide (PA) | ||
 TE Connectivity AMP Connectors | 1 | Chassis Panel Through Hole | 105 C | Solder Turret | Black | Barrier Block | 3 Wall (Tri) | 22 AWG | 17.5 AWG | Steel | 10 | Clear Chromate Zinc | 300 VDC | 25 A | 10 | Screws | 9.53 mm | 0.375 in | UL94 V-0 | Nylon Polyamide (PA) | |||
TE Connectivity AMP Connectors | 1 | Chassis Panel Through Hole | 105 C | Solder Turret | Black | Barrier Block | Flange | 3 Wall (Tri) | 22 AWG | 12 AWG | Steel | Clear Chromate Zinc | 300 VDC | 25 A | 28 | Screws with Captive Plate | 9.53 mm | 0.375 in | UL94 V-0 | Nylon Polyamide (PA) | 28 | ||
TE Connectivity AMP Connectors | 1 | Chassis Panel Through Hole | 105 C | Solder Turret | Black | Barrier Block | Flange | 3 Wall (Tri) | 22 AWG | 12 AWG | Steel | 8 | Clear Chromate Zinc | 300 VDC | 25 A | 8 | Screws with Captive Plate | 9.53 mm | 0.375 in | UL94 V-0 | Nylon Polyamide (PA) | ||
TE Connectivity AMP Connectors | 1 | Chassis Panel Through Hole | 105 C | Solder Turret | Black | Barrier Block | Flange | 3 Wall (Tri) | 22 AWG | 12 AWG | Steel | 10 | Clear Chromate Zinc | 300 VDC | 25 A | 10 | Screws with Captive Plate | 9.53 mm | 0.375 in | UL94 V-0 | Nylon Polyamide (PA) | ||
TE Connectivity AMP Connectors | 1 | Chassis Panel Through Hole | 105 C | Solder Turret | Black | Barrier Block | Flange | 3 Wall (Tri) | 22 AWG | 12 AWG | Steel | 7 | Clear Chromate Zinc | 300 VDC | 25 A | Screws with Captive Plate | 9.53 mm | 0.375 in | UL94 V-0 | Nylon Polyamide (PA) | 7 | ||
 TE Connectivity AMP Connectors | 1 | Chassis Panel Through Hole | 105 C | Solder Turret | Black | Barrier Block | Flange | 3 Wall (Tri) | 22 AWG | 12 AWG | Steel | 4 | Clear Chromate Zinc | 300 VDC | 25 A | 4 | Screws with Captive Plate | 9.53 mm | 0.375 in | UL94 V-0 | Nylon Polyamide (PA) |
