896-010 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 10POS 0.125
| Part | Material - Insulation | Termination Rows | Pitch | Pitch | Operating Temperature [Max] | Operating Temperature [Min] | Mounting Type | Contact Finish Thickness | Contact Finish Thickness | Gender | Number of Positions/Bay/Row | Contact Type | Card Type | Read Out | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Termination | Color | Number of Rows | Number of Positions | Contact Material | Card Thickness [Max] | Card Thickness [Min] | Contact Finish | Termination Rows [custom] | Number of Rows [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 3.18 mm | 0.125 in | 125 °C | -40 C | Through Hole | 0.25 Ám | 10 Áin | Female | 10 | Cantilever | Non Specified - Single Edge | Single | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | Solder Eyelet(s) | Black | 1 | 10 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | ||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 3.18 mm | 0.125 in | 125 °C | -40 C | Through Hole | 0.25 Ám | 10 Áin | Female | 10 | Cantilever | Non Specified - Single Edge | Single | 0.156 " | 3.96 mm | Solder | Black | 1 | 10 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 3.18 mm | 0.125 in | 125 °C | -40 C | Through Hole | 0.25 Ám | 10 Áin | Female | 5 | Cantilever | Non Specified - Dual Edge | Dual | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | Solder | Black | 10 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 2 | 2 | ||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 3.18 mm | 0.125 in | 125 °C | -40 C | Through Hole | 0.25 Ám | 10 Áin | Female | 5 | Cantilever | Non Specified - Dual Edge | Dual | 0.128 " | 3.25 mm | Solder | Black | 10 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 2 | 2 | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 3.18 mm | 0.125 in | 125 °C | -40 C | Right Angle Through Hole | 0.25 Ám | 10 Áin | Female | 10 | Cantilever | Non Specified - Single Edge | Single | Floating Bobbin Flush Mount | 0.116 " | 2.95 mm | Solder | Black | 1 | 10 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | ||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 3.18 mm | 0.125 in | 125 °C | -40 C | Right Angle Through Hole | 0.25 Ám | 10 Áin | Female | 5 | Cantilever | Non Specified - Dual Edge | Dual | Flush Mount M3 Threaded Insert Top Opening | Solder | Black | 10 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 2 | 2 | ||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 3.18 mm | 0.125 in | 125 °C | -40 C | Through Hole | 0.25 Ám | 10 Áin | Female | 5 | Cantilever | Non Specified - Dual Edge | Dual | 4-40 Flush Mount Threaded Insert Top Opening | Solder | Black | 10 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 2 | 2 | ||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 3.18 mm | 0.125 in | 125 °C | -40 C | Through Hole | 0.25 Ám | 10 Áin | Female | 5 | Cantilever | Non Specified - Dual Edge | Dual | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | Solder Eyelet(s) | Black | 10 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 2 | 2 | ||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 3.18 mm | 0.125 in | 125 °C | -40 C | Through Hole | 0.25 Ám | 10 Áin | Female | 10 | Cantilever | Non Specified - Single Edge | Single | 0.156 " | 3.96 mm | Solder | Black | 1 | 10 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 3.18 mm | 0.125 in | 125 °C | -40 C | Through Hole | 0.25 Ám | 10 Áin | Female | 10 | Cantilever | Non Specified - Single Edge | Single | 0.128 " | 3.25 mm | Wire Wrap | Black | 1 | 10 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold |
