887-043 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 43POS 0.156
| Part | Material - Insulation | Termination Rows | Contact Finish | Read Out | Color | Contact Finish Thickness | Contact Finish Thickness | Number of Positions | Gender | Card Type | Pitch | Pitch | Number of Positions/Bay/Row | Termination | Operating Temperature [Max] | Operating Temperature [Min] | Mounting Type | Number of Rows | Contact Type | Card Thickness [Max] | Card Thickness [Min] | Contact Material | Flange Feature [diameter] | Flange Feature [diameter] | Flange Feature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | Gold | Single | Black | 0.25 Ám | 10 Áin | 43 | Female | Non Specified - Single Edge | 3.96 mm | 0.156 in | 43 | Solder | 125 °C | -40 C | Through Hole | 1 | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | Gold | Single | Black | 0.25 Ám | 10 Áin | 43 | Female | Non Specified - Single Edge | 3.96 mm | 0.156 in | 43 | Solder | 125 °C | -40 C | Through Hole | 1 | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | 3.25 mm | 0.128 " | |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | Gold | Single | Black | 0.25 Ám | 10 Áin | 43 | Female | Non Specified - Single Edge | 3.96 mm | 0.156 in | 43 | Solder | 125 °C | -40 C | Through Hole | 1 | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | 3.25 mm | 0.128 " | Side Mount Opening Unthreaded |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | Gold | Single | Black | 0.25 Ám | 10 Áin | 43 | Female | Non Specified - Single Edge | 3.96 mm | 0.156 in | 43 | Solder | 125 °C | -40 C | Right Angle Through Hole | 1 | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | 4-40 Flush Mount Threaded Insert Top Opening | ||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | Gold | Single | Black | 0.25 Ám | 10 Áin | 43 | Female | Non Specified - Single Edge | 3.96 mm | 0.156 in | 43 | Solder | 125 °C | -40 C | Through Hole | 1 | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | 4-40 Flush Mount Threaded Insert Top Opening | ||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | Gold | Single | Black | 0.25 Ám | 10 Áin | 43 | Female | Non Specified - Single Edge | 3.96 mm | 0.156 in | 43 | Solder Eyelet(s) | 125 °C | -40 C | Through Hole | 1 | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | M3 Threaded Insert Top Mount Opening | ||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | Gold | Single | Black | 0.25 Ám | 10 Áin | 43 | Female | Non Specified - Single Edge | 3.96 mm | 0.156 in | 43 | Wire Wrap | 125 °C | -40 C | Through Hole | 1 | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | 2.95 mm | 0.116 " | Floating Bobbin Flush Mount |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | Gold | Single | Black | 0.25 Ám | 10 Áin | 43 | Female | Non Specified - Single Edge | 3.96 mm | 0.156 in | 43 | Wire Wrap | 125 °C | -40 C | Through Hole | 1 | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | 3.25 mm | 0.128 " | Side Mount Opening Unthreaded |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | Gold | Single | Black | 0.25 Ám | 10 Áin | 43 | Female | Non Specified - Single Edge | 3.96 mm | 0.156 in | 43 | Solder | 125 °C | -40 C | Through Hole | 1 | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | 4-40 Flush Mount Threaded Insert Top Opening | ||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | Gold | Single | Black | 0.25 Ám | 10 Áin | 43 | Female | Non Specified - Single Edge | 3.96 mm | 0.156 in | 43 | Solder | 125 °C | -40 C | Through Hole | 1 | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | 3.96 mm | 0.156 " | Flush Mount Top Opening Unthreaded |
