xs Series

Catalog

INDUCTIVE PROXIMITY SENSOR, CYLINDRICAL, OSISENSE XS, M12, 2 MM, PNP-NC, 12 TO 24 VDC, PRE-WIRED

Part	Package / Case	Voltage - Supply [Min]	Voltage - Supply [Max]	Indicator	Termination Style	Ingress Protection	Shielding	Sensing Distance	Sensing Distance	Material - Body	Output Type	Output Type	Sensor Type	Operating Temperature [Min]	Operating Temperature [Max]	Voltage - Supply
SCHNEIDER ELECTRIC XS112BLPBL2	Cylinder Threaded - M12	12 VDC	24 V	LED	Cable Leads	IP67	Unshielded	2 mm	0.079 in	Nickel-Plated Brass	3	PNP-NC	Inductive	-25 °C	70 °C
SCHNEIDER ELECTRIC XS4P12PA370L1	Cylinder Threaded - M18			LED	Cable Leads	IP68	Unshielded	4 mm	0.157 in	Polyphenylene Sulfide (PPS)	3	PNP-NO	Inductive	-25 °C	70 °C
SCHNEIDER ELECTRIC XS4P12KP340	Cylinder Threaded - M12	12 VDC	24 V	LED	Cable	IP68	Shielded	4 mm	0.157 in	Plastic		4-Wire NPN/PNP-NC/NO	Inductive	-25 °C	70 °C
SCHNEIDER ELECTRIC XS4P30NA340	Cylinder Threaded - M30	12 VDC	24 V	LED	Cable	IP68	Shielded	15 mm	0.591 in	Plastic		3-Wire NPN-NO	Inductive	-25 °C	70 °C
SCHNEIDER ELECTRIC XS630B4PAL2	Cylinder Threaded - M30			LED	Cable	IP68	Shielded	22 mm	0.866 "	Metal	3	PNP-NO	Inductive	-25 °C	70 °C
SCHNEIDER ELECTRIC XS2M30MA250K	Cylinder Threaded - M30	24 VAC	240 VAC	LED	Connector	IP67	Unshielded	15 mm	0.591 in	Nickel-Plated Brass		2-Wire NO	Inductive	-25 °C	70 °C	210 VDC
SCHNEIDER ELECTRIC XS8D1A1PBL2	Module	12 VDC	24 V	No Indicator	Cable	IP68	Unshielded	40 mm	1.575 in	Polybutylene Terephthalate (PBT)	3	PNP-NC	Inductive	-25 °C	70 °C
SCHNEIDER ELECTRIC XS4P18MB230	Cylinder Threaded - M18	24 VAC	240 VAC	LED	Cable Leads	IP68	Unshielded	8 mm	0.315 in	Polyphenylene Sulfide (PPS)		2-Wire NC	Inductive	-25 °C	70 °C
SCHNEIDER ELECTRIC XS212SAPAL2	Cylinder Threaded - M12	12 VDC	24 V	LED	Cable	IP68 IP69K	Shielded	7 mm	0.276 in	Stainless Steel		PNP	Inductive	-25 °C	85 °C
SCHNEIDER ELECTRIC XS130B3PAL5	Cylinder Threaded - M30	12 VDC	24 V	LED	Cable	IP65	Unshielded	15 mm	0.591 in	Nickel-Plated Brass	3	NO	Inductive	-25 °C	70 °C
